MPL-AL6060 Series
Manufacturer: Monolithic Power Systems Inc.
Beta
⌘K
FIXED IND 4.7UH 10A 12 MOHM SMD
| Part | Height - Seated (Max) | Height - Seated (Max) [Max] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [x] | Size / Dimension [y] | Inductance Frequency - Test | Mounting Type | DC Resistance (DCR) | Operating Temperature [Min] | Operating Temperature [Max] | Inductance | Current - Saturation (Isat) | Shielding | Current Rating (Amps) | Type | Package / Case |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Monolithic Power Systems Inc. | 6 mm | 0.236 " | 6.4 mm | 6.6 mm | 0.26 in | 0.252 in | 100 kHz | Surface Mount | 12 mOhm | -40 C | 155 C | 4.7 ÁH | 9 A | Unshielded | 10 A | Molded | 2-SMD |
Monolithic Power Systems Inc. | 6 mm | 0.236 " | 6.4 mm | 6.6 mm | 0.26 in | 0.252 in | 100 kHz | Surface Mount | 19 mOhm | -40 C | 155 C | 8.2 µH | 7 A | Unshielded | 8 A | Molded | 2-SMD |
Monolithic Power Systems Inc. | 6 mm | 0.236 " | 6.4 mm | 6.6 mm | 0.26 in | 0.252 in | 100 kHz | Surface Mount | 35 mOhm | -40 C | 155 C | 15 µH | 5.5 A | Unshielded | 5.8 A | Molded | 2-SMD |
 Monolithic Power Systems Inc. | 6 mm | 0.236 " | 6.4 mm | 6.6 mm | 0.26 in | 0.252 in | 100 kHz | Surface Mount | 13 mOhm | -40 C | 155 C | 5.6 µH | 8.6 A | Unshielded | 9.4 A | Molded | 2-SMD |
Monolithic Power Systems Inc. | 6 mm | 0.236 " | 6.4 mm | 6.6 mm | 0.26 in | 0.252 in | 100 kHz | Surface Mount | 24 mOhm | -40 C | 155 C | 10 µH | 6.6 A | Unshielded | 6.9 A | Molded | 2-SMD |
Monolithic Power Systems Inc. | 6 mm | 0.236 " | 6.4 mm | 6.6 mm | 0.26 in | 0.252 in | 100 kHz | Surface Mount | 16 mOhm | -40 C | 155 C | 6.8 µH | 8 A | Unshielded | 8.5 A | Molded | 2-SMD |
