387-017 Series
Manufacturer: EDAC Inc.
Catalog
CONN EDGE SGL FMALE 17POS 0.156
...
| Part | Flange Feature [diameter] | Flange Feature | Flange Feature [diameter] | Termination | Termination Rows | Gender | Read Out | Mounting Type | Color | Contact Finish Thickness | Contact Finish Thickness | Card Thickness [Min] | Card Thickness [Min] | Card Thickness [Max] | Card Thickness [Max] | Pitch [x] | Pitch [x] | Contact Type | Operating Temperature [Min] | Operating Temperature [Max] | Number of Rows | Contact Material | Contact Finish | Card Type | Material - Insulation | Flange Feature | Flange Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 3.96 mm | Flush Mount Top Opening Unthreaded | 0.156 in | Solder | 1 | Female | Single | Through Hole | Black | 10 Áin | 0.25 Ám | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 0.156 in | 3.96 mm | Cantilever | -40 °C | 105 ░C | 1 | Copper Alloy | Gold | Non Specified - Single Edge | Polyester Thermoplastic | ||
 EDAC Inc. | Side Mount Opening Unthreaded | Solder | 1 | Female | Single | Through Hole | Black | 10 Áin | 0.25 Ám | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 0.156 in | 3.96 mm | Cantilever | -40 °C | 105 ░C | 1 | Copper Alloy | Gold | Non Specified - Single Edge | Polyester Thermoplastic | 3.25 mm | 0.128 in | ||
 EDAC Inc. | Flush Mount M3 Threaded Insert Top Opening | Wire Wrap | 1 | Female | Single | Through Hole | Black | 10 Áin | 0.25 Ám | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 0.156 in | 3.96 mm | Cantilever | -40 °C | 105 ░C | 1 | Copper Alloy | Gold | Non Specified - Single Edge | Polyester Thermoplastic | ||||
 EDAC Inc. | 3.96 mm | Flush Mount Top Opening Unthreaded | 0.156 in | Wire Wrap | 1 | Female | Single | Through Hole Right Angle | Black | 10 Áin | 0.25 Ám | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 0.156 in | 3.96 mm | Cantilever | -40 °C | 105 ░C | 1 | Copper Alloy | Gold | Non Specified - Single Edge | Polyester Thermoplastic | ||
 EDAC Inc. | Flush Mount M3 Threaded Insert Top Opening | Solder | 1 | Female | Single | Through Hole | Black | 10 Áin | 0.25 Ám | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 0.156 in | 3.96 mm | Cantilever | -40 °C | 105 ░C | 1 | Copper Alloy | Gold | Non Specified - Single Edge | Polyester Thermoplastic | ||||
 EDAC Inc. | 3.96 mm | Flush Mount Top Opening Unthreaded | 0.156 in | Wire Wrap | 1 | Female | Single | Through Hole | Black | 10 Áin | 0.25 Ám | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 0.156 in | 3.96 mm | Cantilever | -40 °C | 105 ░C | 1 | Copper Alloy | Gold | Non Specified - Single Edge | Polyester Thermoplastic | ||
 EDAC Inc. | 3.25 mm | Flush Mount Top Opening Unthreaded | 0.128 " | Wire Wrap | 1 | Female | Single | Through Hole Right Angle | Black | 10 Áin | 0.25 Ám | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 0.156 in | 3.96 mm | Cantilever | -40 °C | 105 ░C | 1 | Copper Alloy | Gold | Non Specified - Single Edge | Polyester Thermoplastic | ||
 EDAC Inc. | 3.25 mm | Flush Mount Side Opening Unthreaded | 0.128 " | Wire Wrap | 1 | Female | Single | Through Hole Right Angle | Black | 10 Áin | 0.25 Ám | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 0.156 in | 3.96 mm | Cantilever | -40 °C | 105 ░C | 1 | Copper Alloy | Gold | Non Specified - Single Edge | Polyester Thermoplastic | ||
 EDAC Inc. | 2.95 mm | Floating Bobbin Flush Mount | 0.116 in | Wire Wrap | 1 | Female | Single | Through Hole | Black | 10 Áin | 0.25 Ám | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 0.156 in | 3.96 mm | Cantilever | -40 °C | 105 ░C | 1 | Copper Alloy | Gold | Non Specified - Single Edge | Polyester Thermoplastic | ||
 EDAC Inc. | 3.25 mm | Flush Mount Top Opening Unthreaded | 0.128 " | Solder | 1 | Female | Single | Through Hole | Black | 10 Áin | 0.25 Ám | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 0.156 in | 3.96 mm | Cantilever | -40 °C | 105 ░C | 1 | Copper Alloy | Gold | Non Specified - Single Edge | Polyester Thermoplastic |
