887-041 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 41POS 0.156
| Part | Material - Insulation | Termination Rows | Operating Temperature [Max] | Operating Temperature [Min] | Gender | Contact Type | Contact Finish Thickness | Contact Finish Thickness | Number of Rows | Card Thickness [Max] | Card Thickness [Min] | Contact Finish | Flange Feature | Color | Mounting Type | Pitch | Pitch | Termination | Number of Positions | Card Type | Number of Positions/Bay/Row | Read Out | Contact Material | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 125 °C | -40 C | Female | Cantilever | 0.25 Ám | 10 Áin | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 4-40 Threaded Insert Top Mount Opening | Black | Right Angle Through Hole | 3.96 mm | 0.156 in | Solder | 41 | Non Specified - Single Edge | 41 | Single | Copper Alloy | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 125 °C | -40 C | Female | Cantilever | 0.25 Ám | 10 Áin | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Black | Through Hole | 3.96 mm | 0.156 in | Solder | 41 | Non Specified - Single Edge | 41 | Single | Copper Alloy | 0.156 " | 3.96 mm | |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 125 °C | -40 C | Female | Cantilever | 0.25 Ám | 10 Áin | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Flush Mount M3 Threaded Insert Top Opening | Black | Through Hole | 3.96 mm | 0.156 in | Solder | 41 | Non Specified - Single Edge | 41 | Single | Copper Alloy | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 125 °C | -40 C | Female | Cantilever | 0.25 Ám | 10 Áin | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Floating Bobbin Flush Mount | Black | Through Hole | 3.96 mm | 0.156 in | Wire Wrap | 41 | Non Specified - Single Edge | 41 | Single | Copper Alloy | 0.116 " | 2.95 mm |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 125 °C | -40 C | Female | Cantilever | 0.25 Ám | 10 Áin | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Floating Bobbin Flush Mount | Black | Through Hole | 3.96 mm | 0.156 in | Solder | 41 | Non Specified - Single Edge | 41 | Single | Copper Alloy | 0.116 " | 2.95 mm |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 125 °C | -40 C | Female | Cantilever | 0.25 Ám | 10 Áin | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | M3 Threaded Insert Top Mount Opening | Black | Through Hole | 3.96 mm | 0.156 in | Wire Wrap | 41 | Non Specified - Single Edge | 41 | Single | Copper Alloy | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 125 °C | -40 C | Female | Cantilever | 0.25 Ám | 10 Áin | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Side Mount Opening Unthreaded | Black | Through Hole | 3.96 mm | 0.156 in | Wire Wrap | 41 | Non Specified - Single Edge | 41 | Single | Copper Alloy | 0.128 " | 3.25 mm |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 125 °C | -40 C | Female | Cantilever | 0.25 Ám | 10 Áin | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Black | Through Hole | 3.96 mm | 0.156 in | Solder Eyelet(s) | 41 | Non Specified - Single Edge | 41 | Single | Copper Alloy | 0.128 " | 3.25 mm | |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 125 °C | -40 C | Female | Cantilever | 0.25 Ám | 10 Áin | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Flush Mount Side Opening Unthreaded | Black | Right Angle Through Hole | 3.96 mm | 0.156 in | Solder | 41 | Non Specified - Single Edge | 41 | Single | Copper Alloy | 0.128 " | 3.25 mm |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 125 °C | -40 C | Female | Cantilever | 0.25 Ám | 10 Áin | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Flush Mount Top Opening Unthreaded | Black | Through Hole | 3.96 mm | 0.156 in | Solder | 41 | Non Specified - Single Edge | 41 | Single | Copper Alloy | 0.156 " | 3.96 mm |
