5300UP Series

Catalog

CABLE 2COND 18AWG GREEN

Part	Voltage	Length	Length	Conductor Strand [custom]	Conductor Strand [custom]	Wire Gauge	Jacket (Insulation) Material	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Thickness [x]	Jacket (Insulation) Thickness [x]	Number of Conductors	Features	Conductor Material	Usage	Cable Type	Jacket Color	Conductor Insulation
Belden Inc. 5300UP 005U500	300 VDC	152.4 m	500 ft	34	42	18 AWG	Poly-Vinyl Chloride (PVC)	4.67 mm	0.184 in	0.381 mm	0.015 in	2	Rip Cord	Copper Bare	Commercial Audio	Multi-Conductor	Green	Poly-Vinyl Chloride (PVC)
Belden Inc. 5300UP D15U1000	300 VDC	304.8 m	1000 ft	34	42	18 AWG	Poly-Vinyl Chloride (PVC)	4.67 mm	0.184 in	0.381 mm	0.015 in	2	Rip Cord	Copper Bare	Commercial Audio	Multi-Conductor	Blue	Poly-Vinyl Chloride (PVC)
Belden Inc. 5300UP D151000	300 VDC	304.8 m	1000 ft	34	42	18 AWG	Poly-Vinyl Chloride (PVC)	4.67 mm	0.184 in	0.381 mm	0.015 in	2	Rip Cord	Copper Bare	Commercial Audio	Multi-Conductor	Blue	Poly-Vinyl Chloride (PVC)
Belden Inc. 5300UP 0051000	300 VDC	304.8 m	1000 ft	34	42	18 AWG	Poly-Vinyl Chloride (PVC)	4.67 mm	0.184 in	0.381 mm	0.015 in	2	Rip Cord	Copper Bare	Commercial Audio	Multi-Conductor	Green	Poly-Vinyl Chloride (PVC)
Belden Inc. 5300UP 009U1000	300 VDC	304.8 m	1000 ft	34	42	18 AWG	Poly-Vinyl Chloride (PVC)	4.67 mm	0.184 in	0.381 mm	0.015 in	2	Rip Cord	Copper Bare	Commercial Audio	Multi-Conductor	White	Poly-Vinyl Chloride (PVC)
