073358 Series

Manufacturer: Molex

Catalog

SSMCX SMT PCB 6 PORT 50 OHM

Part	Mounting Type	Body Finish	Frequency - Max [Max]	Dielectric Material	Fastening Type	Connector Style	Housing Color	Center Contact Plating	Number of Ports	Features	Shield Termination	Center Contact Material	Voltage Rating	Impedance	Contact Termination	Connector Type	Body Material	Contact Finish	Color	Number of Positions	Operating Temperature [Max]	Operating Temperature [Min]	Pitch [x]	Pitch [x]	Connector Usage	Number of Rows	Contact Layout, Typical	Number of Positions Loaded	Contact Finish Thickness	Contact Finish Thickness
Molex 0733580680	Surface Mount Through Hole	Gold	6000 MHz	Polytetrafluoroethylene (PTFE)	Snap-On	SSMCX	Gold	Gold	6	Board Guide	Solder	Beryllium Copper	170 V	50 Ohms	Solder	Female Socket Jack	Brass
Molex 0733581120						VITA 67.1				Guide Pin						Module		Gold	Silver	4	85 °C	-55 °C	6.1 mm	0.24 in	Daughtercard	2	4 Coax
Molex 0733580320	Surface Mount Through Hole	Gold	6000 MHz	Polytetrafluoroethylene (PTFE)	Snap-On	SSMCX	Gold	Gold	4	Board Guide	Solder	Beryllium Copper	170 V	50 Ohms	Solder	Female Socket Jack	Brass
Molex 0733580272	Board Edge End Launch		6000 MHz		Snap-On	SSMCX	Gold		6		Solder		170 V	50 Ohms	Solder	Female Socket Jack
Molex 0733581270						VITA 67.1				Guide Pin						Module			Silver	4			6.1 mm	0.24 in	Daughtercard	2	4 Coax
Molex 0733581150						VITA 67.2				Guide Pin						Module		Gold	Silver	8	85 °C	-55 °C	6.1 mm	0.24 in	Backplane Midplane Orthogonal	2		All	50 µin	1.27 µm
Molex 0733580762	Through Hole Right Angle	Gold	6000 MHz	Polytetrafluoroethylene (PTFE)	Snap-On	SSMCX	Gold	Gold	6		Solder	Beryllium Copper	170 V	75 Ohms	Solder	Female Socket Jack	Brass
Molex 0733580270	Board Edge End Launch		6000 MHz		Snap-On	SSMCX	Gold		4		Solder		170 V	50 Ohms	Solder	Female Socket Jack
