1744194 Series
Manufacturer: TE Connectivity Raychem Cable Protection
Beta
⌘K
CONN HEADER VERT 8POS 3.96MM
| Part | Connector Type | Insulation Color | Applications | Contact Type | Contact Finish - Post | Voltage Rating | Shrouding | Termination | Number of Positions | Contact Shape | Number of Rows | Current Rating (Amps) | Contact Length - Mating | Contact Length - Mating | Fastening Type | Overall Contact Length | Overall Contact Length | Insulation Height | Insulation Height | Material Flammability Rating | Contact Length - Post [x] | Contact Length - Post [x] | Contact Material | Mounting Type | Pitch - Mating | Pitch - Mating | Number of Positions Loaded | Operating Temperature [Max] | Operating Temperature [Min] | Style |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
TE Connectivity Raychem Cable Protection | Header | Natural | General Purpose Industrial | Male Pin | Tin | 600 VAC | Shrouded - 1 Wall | Solder | 8 | Square | 1 | Varies by Wire Gauge | 0.3 in | 7.62 mm | Friction Lock | 0.55 in | 13.97 mm | 0.425 in | 10.8 mm | UL94 V-0 | 3.18 mm | 0.125 in | Copper Alloy | Through Hole | 0.156 in | 3.96 mm | All | 105 ░C | -55 °C | Board to Cable/Wire |
 TE Connectivity Raychem Cable Protection | Header | Natural | General Purpose Industrial | Male Pin | Tin | 600 VAC | Shrouded - 1 Wall | Solder | 7 | Square | 1 | Varies by Wire Gauge | 0.3 in | 7.62 mm | Friction Lock | 0.55 in | 13.97 mm | 0.425 in | 10.8 mm | UL94 V-0 | 3.18 mm | 0.125 in | Copper Alloy | Through Hole | 0.156 in | 3.96 mm | All | 105 ░C | -55 °C | Board to Cable/Wire |
