HDSP-570 Series
Manufacturer: Broadcom Limited
Beta
⌘K
S4,0.56S,ALLNGAPYEL,CC
| Part | Number of Characters | Wavelength - Peak | Display Type | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [z] | Power Dissipation (Max) [Max] | Common Pin | Package / Case | Package / Case | Current - Test | Millicandela Rating | Digit/Alpha Size | Digit/Alpha Size | Voltage - Forward (Vf) (Typ) | Color | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [x] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Broadcom Limited | 1 | 583 nm | 7-Segment | 0.315 " | 0.495 " | 0.673 " | 12.57 mm | 17.1 mm | 8 mm | 80 mW | Common Cathode | 0.6 in 15.24 mm | 10-DIP | 20 mA | 2.75 mcd | 0.56 in | 14.22 mm | 2.1 V | Yellow | |||
 Broadcom Limited | 1 | 583 nm | 7-Segment | 0.315 " | 0.495 " | 0.673 " | 12.57 mm | 17.1 mm | 8 mm | 80 mW | Common Anode | 0.6 in 15.24 mm | 10-DIP | 20 mA | 1.8 mcd | 0.56 in | 14.22 mm | 2.1 V | Yellow | |||
 Broadcom Limited | 1 | 583 nm | 7-Segment | 17.02 mm | 12.57 mm | 8 mm | 80 mW | Common Cathode | 0.6 in 15.24 mm | 10-DIP | 20 mA | 1.8 mcd | 0.56 in | 14.22 mm | 2.1 V | Yellow | 0.67 in | 0.495 " | 0.315 in | |||
 Broadcom Limited | 1 | 583 nm | 7-Segment | 0.315 " | 0.495 " | 0.673 " | 12.57 mm | 17.1 mm | 8 mm | 80 mW | Common Anode | 0.6 in 15.24 mm | 10-DIP | 20 mA | 2.75 mcd | 0.56 in | 14.22 mm | 2.1 V | Yellow |
