PTP15 Series
Manufacturer: CUI Inc.
Beta
⌘K
ISOLATED DC/DC CONVERTERS - THROUGH HOLE DC-DC, ISOLATED, 15 W, 36-75 VDC INPUT, 12 VDC, 1.25 A, SINGLE REGULATED OUTPUT, DIP, MED
| Part | Operating Temperature [Max] | Operating Temperature [Min] | Applications | Approval Agency | Package / Case | Voltage - Output 1 | Voltage - Input (Min) [Min] | Efficiency | Voltage - Input (Max) [Max] | Power (Watts) | Number of Outputs | Type | Current - Output (Max) [Max] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [x] | Size / Dimension [z] | Standard Number | Mounting Type | Voltage - Isolation |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 CUI Inc. | 105 C | -40 °C | Medical | CE UKCA | 5-DIP Module 4 Leads | 12 V | 36 V | 88 % | 75 V | 15 W | 1 | Isolated Module | 1.25 A | 25.4 mm | 0.47 " | 1 " | 50.8 mm | 2 in | 12 mm | 60601-1 | Through Hole | 5.6 kV |
