845-061 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 61POS 0.100
| Part | Material - Insulation | Termination Rows | Contact Finish | Number of Positions/Bay/Row | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Card Type | Color | Card Thickness [Max] | Card Thickness [Min] | Contact Material | Termination | Gender | Contact Type | Number of Positions | Number of Rows | Operating Temperature [Max] | Operating Temperature [Min] | Contact Finish Thickness | Contact Finish Thickness | Mounting Type | Read Out | Pitch | Pitch |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Gold | 61 | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | Non Specified - Single Edge | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Solder | Female | Cantilever | 61 | 1 | 125 °C | -40 C | 0.25 Ám | 10 Áin | Through Hole | Single | 0.1 " | 2.54 mm |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Gold | 61 | 4-40 Threaded Insert Top Mount Opening | Non Specified - Single Edge | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Wire Wrap | Female | Cantilever | 61 | 1 | 125 °C | -40 C | 0.25 Ám | 10 Áin | Through Hole | Single | 0.1 " | 2.54 mm | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Gold | 61 | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | Non Specified - Single Edge | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Solder | Female | Cantilever | 61 | 1 | 125 °C | -40 C | 0.25 Ám | 10 Áin | Right Angle Through Hole | Single | 0.1 " | 2.54 mm |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Gold | 61 | 4-40 Flush Mount Threaded Insert Top Opening | Non Specified - Single Edge | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Solder | Female | Cantilever | 61 | 1 | 125 °C | -40 C | 0.25 Ám | 10 Áin | Through Hole | Single | 0.1 " | 2.54 mm | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Gold | 61 | 0.128 " | 3.25 mm | Non Specified - Single Edge | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Solder Eyelet(s) | Female | Cantilever | 61 | 1 | 125 °C | -40 C | 0.25 Ám | 10 Áin | Through Hole | Single | 0.1 " | 2.54 mm | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Gold | 61 | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | Non Specified - Single Edge | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Wire Wrap | Female | Cantilever | 61 | 1 | 125 °C | -40 C | 0.25 Ám | 10 Áin | Through Hole | Single | 0.1 " | 2.54 mm |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Gold | 61 | 0.128 " | 3.25 mm | Non Specified - Single Edge | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Solder | Female | Cantilever | 61 | 1 | 125 °C | -40 C | 0.25 Ám | 10 Áin | Right Angle Through Hole | Single | 0.1 " | 2.54 mm | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Gold | 61 | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | Non Specified - Single Edge | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Solder | Female | Cantilever | 61 | 1 | 125 °C | -40 C | 0.25 Ám | 10 Áin | Right Angle Through Hole | Single | 0.1 " | 2.54 mm |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Gold | 61 | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | Non Specified - Single Edge | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Wire Wrap | Female | Cantilever | 61 | 1 | 125 °C | -40 C | 0.25 Ám | 10 Áin | Through Hole | Single | 0.1 " | 2.54 mm |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Gold | 61 | 4-40 Flush Mount Threaded Insert Top Opening | Non Specified - Single Edge | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Solder | Female | Cantilever | 61 | 1 | 125 °C | -40 C | 0.25 Ám | 10 Áin | Right Angle Through Hole | Single | 0.1 " | 2.54 mm |
