307-012 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 24POS 0.156
| Part | Termination Rows | Material - Insulation | Number of Positions | Read Out | Contact Material | Mounting Type | Gender | Contact Finish Thickness | Contact Finish Thickness | Operating Temperature [Min] | Operating Temperature [Max] | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Number of Rows [custom] | Card Type | Termination | Color | Contact Finish | Contact Type | Number of Positions/Bay/Row | Pitch | Pitch | Card Thickness [Max] | Card Thickness [Min] | Features | Number of Rows | Termination Rows [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyester Thermoplastic | 24 | Dual | Copper Alloy | Surface Mount | Female | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | 2 | Non Specified - Dual Edge | Solder Eyelet(s) | Green | Gold | Semi Bellows | 12 | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | 12 | Single | Copper Alloy | Through Hole | Female | 0.25 Ám | 10 Áin | -40 C | 105 ░C | 4-40 Flush Mount Threaded Insert Top Opening | Non Specified - Single Edge | Wire Wrap | Green | Gold | Semi Bellows | 12 | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Card Guides | 1 | ||||
 EDAC Inc. | Polyester Thermoplastic | 12 | Dual | Copper Alloy | Board Edge Straddle Mount | Female | 0.25 Ám | 10 Áin | -40 C | 105 ░C | 4-40 Flush Mount Threaded Insert Top Opening | 2 | Non Specified - Dual Edge | Solder Eyelet(s) | Green | Gold | Semi Bellows | 6 | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Card Extender Card Guides | 2 | ||||
 EDAC Inc. | Polyester Thermoplastic | 12 | Dual | Copper Alloy | Board Edge Straddle Mount | Female | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Flush Mount M3 Threaded Insert Top Opening | 2 | Non Specified - Dual Edge | Solder | Green | Gold | Semi Bellows | 6 | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Card Extender | 2 | ||||
 EDAC Inc. | 1 | Polyester Thermoplastic | 24 | Dual | Copper Alloy | Through Hole | Female | 0.25 Ám | 10 Áin | -40 C | 105 ░C | 4-40 Flush Mount Threaded Insert Top Opening | 2 | Non Specified - Dual Edge | Wire Wrap | Green | Gold | Semi Bellows | 12 | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Card Guides | ||||
 EDAC Inc. | Polyester Thermoplastic | 12 | Dual | Copper Alloy | Board Edge Straddle Mount | Female | 0.25 Ám | 10 Áin | -40 C | 105 ░C | 4-40 Flush Mount Threaded Insert Top Opening | 2 | Non Specified - Dual Edge | Solder | Green | Gold | Semi Bellows | 6 | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Card Extender Card Guides | 2 | ||||
 EDAC Inc. | 1 | Polyester Thermoplastic | 12 | Single | Copper Alloy | Right Angle Through Hole | Female | 0.25 Ám | 10 Áin | -40 C | 105 ░C | 4-40 Flush Mount Threaded Insert Top Opening | Non Specified - Single Edge | Solder | Green | Gold | Semi Bellows | 12 | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | |||||
 EDAC Inc. | Polyester Thermoplastic | 12 | Dual | Copper Alloy | Board Edge Straddle Mount | Female | 0.25 Ám | 10 Áin | -40 C | 105 ░C | 2 | Non Specified - Dual Edge | Solder Eyelet(s) | Green | Gold | Semi Bellows | 6 | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Card Extender | 2 | |||||
 EDAC Inc. | Polyester Thermoplastic | 12 | Dual | Copper Alloy | Right Angle Through Hole | Female | 0.25 Ám | 10 Áin | -40 C | 105 ░C | 4-40 Flush Mount Threaded Insert Top Opening | 2 | Non Specified - Dual Edge | Solder Wire Wrap | Green | Gold | Semi Bellows | 6 | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Card Guides | 2 | ||||
 EDAC Inc. | 1 | Polyester Thermoplastic | 12 | Single | Copper Alloy | Right Angle Through Hole | Female | -40 C | 105 ░C | Flush Mount M3 Threaded Insert Top Opening | Non Specified - Single Edge | Solder | Green | Tin | Semi Bellows | 12 | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 |
