AIF04ZPFC Series
Isolated DC/DC Converters - Through Hole 600W 24V@25A 4.6" X 2.4" X 0.5" H
Manufacturer: ARTESYN / Advanced Energy
Catalog
Isolated DC/DC Converters - Through Hole 600W 24V@25A 4.6" X 2.4" X 0.5" H
Beta
⌘K
Isolated DC/DC Converters - Through Hole 600W 24V@25A 4.6" X 2.4" X 0.5" H
Isolated DC/DC Converters - Through Hole 600W 24V@25A 4.6" X 2.4" X 0.5" H
Isolated DC/DC Converters - Through Hole 600W 24V@25A 4.6" X 2.4" X 0.5" H
| Part | Operating Temperature [Min] | Operating Temperature [Max] | Voltage - Output 1 | Mounting Type | Power (Watts) | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [x] | Efficiency | Applications | Voltage - Input [Min] | Voltage - Input [Max] | Package / Case | Number of Outputs | Type | Standard Number | Current - Output (Max) [Max] | Features | Approval Agency |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 ARTESYN / Advanced Energy | -20 ░C | 100 °C | 380 V | Through Hole | 1.6 kW | 4.6 " | 14 mm | 0.55 in | 2.4 in | 61 mm | 116.8 mm | 95 % | ITE (Commercial) | 85 VAC 120 VDC | 264 VAC 370 VDC | 34-DIP Module 24 Leads | 1 | Enclosed | 62368-1 | 4.2 A | Universal Input | cUL TUV UL |
ARTESYN / Advanced Energy | -20 ░C | 100 °C | 380 V | Through Hole | 1.6 kW | 4.6 " | 14 mm | 0.55 in | 2.4 in | 61 mm | 116.8 mm | 95 % | ITE (Commercial) | 85 VAC 120 VDC | 264 VAC 370 VDC | 34-DIP Module 24 Leads | 1 | Enclosed | 62368-1 | 4.2 A | Universal Input | cUL TUV UL |
ARTESYN / Advanced Energy | -20 ░C | 100 °C | 380 V | Through Hole | 1.6 kW | 4.6 " | 14 mm | 0.55 in | 2.4 in | 61 mm | 116.8 mm | 95 % | ITE (Commercial) | 85 VAC 120 VDC | 264 VAC 370 VDC | 34-DIP Module 24 Leads | 1 | Enclosed | 62368-1 | 4.2 A | Universal Input | cUL TUV UL |
 ARTESYN / Advanced Energy | -20 ░C | 100 °C | 380 V | Through Hole | 1.6 kW | 4.6 " | 14 mm | 0.55 in | 2.4 in | 61 mm | 116.8 mm | 95 % | ITE (Commercial) | 85 VAC 120 VDC | 264 VAC 370 VDC | 34-DIP Module 24 Leads | 1 | Enclosed | 62368-1 | 4.2 A | Universal Input | cUL TUV UL |
 ARTESYN / Advanced Energy | -20 ░C | 100 °C | 380 V | Through Hole | 1.6 kW | 4.6 " | 14 mm | 0.55 in | 2.4 in | 61 mm | 116.8 mm | 95 % | ITE (Commercial) | 85 VAC 120 VDC | 264 VAC 370 VDC | 34-DIP Module 24 Leads | 1 | Enclosed | 62368-1 | 4.2 A | Universal Input | cUL TUV UL |
