157.5701.6101 Series

Fuse - Strip 60 w/ Housing 48VDC, 100A

Catalog

Fuse - Strip 60 w/ Housing 48VDC, 100A

Part	Mounting Type	Package / Case	Breaking Capacity @ Rated Voltage	Current Rating (Amps)	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Fuse Type	Voltage Rating - DC	Applications	Operating Temperature [Max]	Operating Temperature [Min]
Littelfuse/Commercial Vehicle Products 157.5701.6101	Bolt Mount	Metal Strip	600 A	100 A	10.5 mm	0.866 in	82 mm	3.228 in	0.413 "	22 mm	Fuse Strip	48 V	Lift Trucks	125 °C	-40 °C

Fuse - Strip 60 w/ Housing 48VDC, 100A

• Tin-plated zinc alloy

• 11 mm lug aperture

• Interrupting rating of 600 A at 48 V dc

• Recognized as a UL 248 Special Purpose Fuse

This 100 A special purpose EV fuse strip comes with its housing. The fuse protects wires rated for 48 V in battery-powered vehicles.
