GT06 Series

Catalog

CONN PLUG FMALE 4P SILVER SCREW

Part	Shell Material	Operating Temperature [Min]	Operating Temperature [Max]	Shell Size - Insert	Shell Finish	Termination	Mounting Type	Color	Number of Positions	Connector Type	Fastening Type	Contact Finish - Mating	Current Rating (Amps)	Ingress Protection	Orientation	Primary Material	Features
Amphenol Industrial Operations GT06PCM32-ARS-70(29OS)	Aluminum	-55 °C	125 °C	32	Olive Drab Cadmium	Screw	Free Hanging (In-Line)	Olive Drab	4	Female Sockets Plug	Reverse Bayonet Lock	Silver	70 A	IP67 - Dust Tight Waterproof	N	Metal	Backshell
Amphenol Industrial Operations GT06PCM32-ARS-30(29R)	Aluminum	-55 °C	125 °C	32	Olive Drab Cadmium	Screw	Free Hanging (In-Line)	Olive Drab	4	Female Sockets Plug	Reverse Bayonet Lock	Silver	30 A	IP67 - Dust Tight Waterproof	N	Metal	Backshell
Amphenol Industrial Operations GT06PCM32-ARS-50(29)	Aluminum	-55 °C	125 °C	32	Olive Drab Cadmium	Screw	Free Hanging (In-Line)	Olive Drab	4	Female Sockets Plug	Reverse Bayonet Lock	Silver	50 A	IP67 - Dust Tight Waterproof	N	Metal	Backshell
Amphenol Industrial Operations GT06PCM32-ARS-40(29R)	Aluminum	-55 °C	125 °C	32	Olive Drab Cadmium	Screw	Free Hanging (In-Line)	Olive Drab	4	Female Sockets Plug	Reverse Bayonet Lock	Silver	40 A	IP67 - Dust Tight Waterproof	N	Metal	Backshell
