841340 Series

Catalog

SSR RELAY SPST-NO 50A 24-280V

Part	Voltage - Input [Min]	Voltage - Input [Max]	Operating Temperature [Max]	Operating Temperature [Min]	Output Type	Voltage - Load [Min]	Voltage - Load [Max]	Termination Style	Load Current	Package / Case	Mounting Type	Approval Agency
Sensata-Crydom 84134020H	3 V	32 VDC	80 °C	-40 C	AC Zero Cross	24 V	280 V	Screw Terminal	50 A	Hockey Puck	Chassis Mount	CE CSA cURus TUV
Sensata-Crydom 84134012	18 VAC/DC	36 VAC	80 °C	-40 C	AC Zero Cross	24 V	280 V	Screw Terminal	25 A	Hockey Puck	Chassis Mount	CE CSA cURus TUV
Sensata-Crydom 84134080	3 V	32 VDC	80 °C	-40 C	AC Zero Cross	24 V	280 V	Screw Terminal	125 A	Hockey Puck	Chassis Mount	CE CSA cURus TUV
Sensata-Crydom 84134021H	90 VAC	280 VAC/DC	80 °C	-40 C	AC Zero Cross	24 V	280 V	Screw Terminal	50 A	Hockey Puck	Chassis Mount	CE CSA cURus TUV
Sensata-Crydom 84134040	3 V	32 VDC	80 °C	-40 C	AC Zero Cross	24 V	280 V	Screw Terminal	100 A	Hockey Puck	Chassis Mount	CE CSA cURus TUV
Sensata-Crydom 84134017	3 V	32 VDC	80 °C	-40 C	AC Zero Cross	24 V	280 V	Quick Connect - 0.250" (6.3mm)	25 A	Hockey Puck	Chassis Mount	CE CSA cURus TUV
