R2E225 Series
Manufacturer: ebm-papst Inc.
Beta
⌘K
BLOWERS & CENTRIFUGAL FANS AC BACKWARD-CURVED MOTORIZED IMPELLER, 115VAC, 185W, 756CFM
| Part | Material - Blade | Power (Watts) | Width [x] | Voltage - Rated | Air Flow | Air Flow | Fan Type | Bearing Type | Noise | Size / Dimension [diameter] | Current Rating (Amps) | Features | Approval Agency | Operating Temperature [Min] | Operating Temperature [Max] | RPM | Termination | Ingress Protection | Width [y] | Termination | Weight [custom] | Weight [custom] | Operating Temperature [Min] | Operating Temperature [Max] | Voltage Range [Min] | Voltage Range [Max] | Size / Dimension |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 ebm-papst Inc. | Polyamide (PA66) Nylon 6/6 | 185 W | 135 mm | 115 VAC | 21.17 m³/min | 756 CFM | Motorized Impellers | Ball | 75 dB(A) | 225 mm | |||||||||||||||||
 ebm-papst Inc. | Polyamide (PA6) Nylon 6 Fiberglass Reinforced | 200 Watts | 230 VAC | Motorized Impellers | Ball | 225 mm | 880 mA | Capacitor Thermal Overload Protector (TOP) | CCC EAC | -25 °C | 55 °C | 2950 RPM | 4 Wire Leads with Splice Terminals | IP44 | 99 mm | ||||||||||||
 ebm-papst Inc. | Polyamide (PA6) Nylon 6 Fiberglass Reinforced | 200 Watts | 28 mm | 230 VAC | Ball | 223 mm | 1.2 A | Capacitor Thermal Overload Protection (TOP) | CCC CSA UL | -25 °C | 55 °C | 2950 RPM | IP44 | 7 Terminals | 2.3 kg | 5 lbs | |||||||||||
 ebm-papst Inc. | 145 W | 230 VAC | Motorized Impellers | Ball | 225 mm | Capacitor Thermal Overload Protector (TOP) | CCC CE EAC | -25 °C | 55 °C | 2950 RPM | 4 Wire Leads with Splice Terminals | IP44 | |||||||||||||||
 ebm-papst Inc. | Polyamide (PA6) Nylon 6 Fiberglass Reinforced | 210 W | 230 VAC | 11.63 mł/min | 415.2 CFM | Motorized Impellers | Ball | 225 mm | 920 mA | Capacitor Thermal Overload Protector (TOP) | CCC CE EAC | -25 °C | 65 °C | 2600 RPM | 4 Wire Leads with Splice Terminals | IP44 | 99 mm | -25 °C | 65 °C | ||||||||
 ebm-papst Inc. | Polyamide (PA) Nylon Fiberglass Reinforced | 225 W | 115 VAC | 22.08 m³/min | 788.7 CFM | Motorized Impellers | Ball | 76 dB(A) | 225 mm | UL | -25 °C | 40 °C | 2700 RPM | 4 Wire Leads | IP44 | 99 mm | 2.3 kg | 5 lbs | -25 °C | 40 °C | 100 VAC | 130 VAC | |||||
 ebm-papst Inc. | Polyamide (PA) Nylon | 185 W | 230 VAC | Motorized Impellers | Ball | 225 mm | 0.81 A | Capacitor Thermal Overload Protector (TOP) | CE CSA UL | -25 °C | 55 °C | 3000 RPM | 3 Wire Leads with Splice Terminals 4 Wire Leads with Splice Terminals | IP44 | 107 mm | ||||||||||||
 ebm-papst Inc. | Steel | 285 W | 186 mm | 230 VAC | Motorized Impellers | Ball | 270 mm | 1.25 A | Capacitor Thermal Overload Protector (TOP) | CE CSA UL | -25 °C | 50 °C | 2800 RPM | 3 Wire Leads with Splice Terminals | IP20 | -25 °C | 50 °C | Round | |||||||||
 ebm-papst Inc. | |||||||||||||||||||||||||||
 ebm-papst Inc. | Polyamide (PA) Nylon | 165 W | 230 VAC | Motorized Impellers | Ball | 225 mm | 0.72 A | Capacitor Thermal Overload Protector (TOP) | CCC CSA UL | -25 °C | 40 °C | 3000 RPM | 4 Wire Leads with Splice Terminals | IP44 | 75.3 mm | -25 °C | 40 °C |
