053476 Series

Manufacturer: Molex

Catalog

MINILOCK 2.5 STR GW NAT 7CKT

Part	Style	Number of Positions	Termination	Number of Rows	Number of Positions Loaded	Shrouding	Voltage Rating	Contact Length - Mating	Contact Length - Mating	Contact Shape	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Mounting Type	Current Rating (Amps)	Insulation Height	Insulation Height	Contact Length - Post [x]	Contact Length - Post [x]	Contact Finish - Post	Fastening Type	Insulation Material	Insulation Color	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Features	Pitch - Mating	Pitch - Mating	Material Flammability Rating	Connector Type	Contact Type	Contact Material	Operating Temperature [Min]	Operating Temperature [Max]
Molex 0534760710	Board to Cable/Wire	7	Kinked Pin Solder	1	All	Shrouded - 4 Wall	250 VAC	4 mm	0.157 in	Circular	1 µm	39.4 µin	Through Hole	Varies by Wire Gauge	11.5 mm	0.453 in	0.134 in	3.4 mm	Tin	Locking Ramp	Glass Filled Nylon Polyamide (PA)	Natural	1 çm	39.4 çin	Board Guide Glow Wire Compliant	2.5 mm	0.098 in	UL94 V-0	Header	Male Pin	Phosphor Bronze	-40 °C	105 ░C
Molex 0534761510	Board to Cable/Wire	15	Kinked Pin Solder	1	All	Shrouded - 4 Wall	250 VAC	4 mm	0.157 in	Circular	1 µm	39.4 µin	Through Hole	Varies by Wire Gauge	11.5 mm	0.453 in	0.134 in	3.4 mm	Tin	Locking Ramp	Glass Filled Nylon Polyamide (PA)	Natural	1 çm	39.4 çin	Board Guide Glow Wire Compliant	2.5 mm	0.098 in	UL94 V-0	Header	Male Pin	Phosphor Bronze	-40 °C	105 ░C
Molex 0534761210
Molex 0534761410	Board to Cable/Wire	14	Kinked Pin Solder	1	All	Shrouded - 4 Wall	250 VAC	4 mm	0.157 in	Circular	1 µm	39.4 µin	Through Hole	Varies by Wire Gauge	11.5 mm	0.453 in	0.134 in	3.4 mm	Tin	Locking Ramp	Glass Filled Nylon Polyamide (PA)	Natural	1 çm	39.4 çin	Board Guide Glow Wire Compliant	2.5 mm	0.098 in	UL94 V-0	Header	Male Pin	Phosphor Bronze	-40 °C	105 ░C
Molex 0534760510	Board to Cable/Wire		Kinked Pin Solder	1	All	Shrouded - 4 Wall	250 VAC	4 mm	0.157 in	Circular	1 µm	39.4 µin	Through Hole	Varies by Wire Gauge	11.5 mm	0.453 in	0.134 in	3.4 mm	Tin	Locking Ramp	Glass Filled Nylon Polyamide (PA)	Natural	1 çm	39.4 çin	Board Guide Glow Wire Compliant	2.5 mm	0.098 in	UL94 V-0	Header	Male Pin	Phosphor Bronze	-40 °C	105 ░C
Molex 0534760810	Board to Cable/Wire	8	Kinked Pin Solder	1	All	Shrouded - 4 Wall	250 VAC	4 mm	0.157 in	Circular	1 µm	39.4 µin	Through Hole	Varies by Wire Gauge	11.5 mm	0.453 in	0.134 in	3.4 mm	Tin	Locking Ramp	Glass Filled Nylon Polyamide (PA)	Natural	1 çm	39.4 çin	Board Guide Glow Wire Compliant	2.5 mm	0.098 in	UL94 V-0	Header	Male Pin	Phosphor Bronze	-40 °C	105 ░C
Molex 0534760910	Board to Cable/Wire	9	Kinked Pin Solder	1	All	Shrouded - 4 Wall	250 VAC	4 mm	0.157 in	Circular	1 µm	39.4 µin	Through Hole	Varies by Wire Gauge	11.5 mm	0.453 in	0.134 in	3.4 mm	Tin	Locking Ramp	Glass Filled Nylon Polyamide (PA)	Natural	1 çm	39.4 çin	Board Guide Glow Wire Compliant	2.5 mm	0.098 in	UL94 V-0	Header	Male Pin	Phosphor Bronze	-40 °C	105 ░C
Molex 0534760210
Molex 0534760410	Board to Cable/Wire	4	Kinked Pin Solder	1	All	Shrouded - 4 Wall	250 VAC	4 mm	0.157 in	Circular	1 µm	39.4 µin	Through Hole	Varies by Wire Gauge	11.5 mm	0.453 in	0.134 in	3.4 mm	Tin	Locking Ramp	Glass Filled Nylon Polyamide (PA)	Natural	1 çm	39.4 çin	Board Guide Glow Wire Compliant	2.5 mm	0.098 in	UL94 V-0	Header	Male Pin	Phosphor Bronze	-40 °C	105 ░C
Molex 0534761310	Board to Cable/Wire	13	Kinked Pin Solder	1	All	Shrouded - 4 Wall	250 VAC	4 mm	0.157 in	Circular	1 µm	39.4 µin	Through Hole	Varies by Wire Gauge	11.5 mm	0.453 in	0.134 in	3.4 mm	Tin	Locking Ramp	Glass Filled Nylon Polyamide (PA)	Natural	1 çm	39.4 çin	Board Guide Glow Wire Compliant	2.5 mm	0.098 in	UL94 V-0	Header	Male Pin	Phosphor Bronze	-40 °C	105 ░C
