LL1105 Series
Manufacturer: E-Switch
Beta
⌘K
MICROSWITCH TACT; SPST; POS: 2; 0.05A/12VDC; SMD; OFF-(ON); ROUND
| Part | Mechanical Life | Switch Travel | Contact Rating @ Voltage | Actuator Orientation | Termination Style | Actuator Height off PCB, Vertical [z] | Outline [x] | Outline [y] | Operating Temperature [Min] | Operating Temperature [Max] | Mounting Type | Switch Function | Circuit | Actuator Type | Operating Force | Illumination |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 E-Switch | 5000000 Cycles | 0.25 mm | 0.05 A 12 VDC | Top Actuated | PC Pin | 5 mm | 6 mm | 6 mm | -20 ░C | 70 °C | Through Hole | Off-Mom | SPST-NO | Standard | 65 gf | Non-Illuminated |
 E-Switch | 5000000 Cycles | 0.25 mm | 0.05 A 12 VDC | Top Actuated | PC Pin | 9.5 mm | 6 mm | 6 mm | -20 ░C | 70 °C | Through Hole | Off-Mom | SPST-NO | Standard | 65 gf | Non-Illuminated |
