R12548 Series
Manufacturer: Radiall USA, Inc.
Beta
⌘K
SMA / 2 HOLE FLANGE PLUG RECEPTA
| Part | Center Contact Plating | Body Material | Operating Temperature [Min] | Operating Temperature [Max] | Mating Cycles | Dielectric Material | Voltage Rating | Body Finish | Frequency - Max [Max] | Connector Style | Housing Color | Features | Mounting Type | Impedance | Contact Termination | Number of Ports | Center Contact Material | Mounting Feature | Shield Termination | Connector Type | Fastening Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Radiall USA, Inc. | Gold | Stainless Steel | -65 ░C | 165 °C | 500 | Polytetrafluoroethylene (PTFE) | 500 V | Gold | 18 GHz | SMA | Gold | Extended Insulation | Panel Mount | 50 Ohms | Solder | 1 | Brass | Flange | Solder | Plug Male Pin | Threaded |
 Radiall USA, Inc. | Gold | Stainless Steel | -65 ░C | 105 ░C | 500 | Polytetrafluoroethylene (PTFE) | 500 V | 18 GHz | SMA | Silver | Panel Mount | 50 Ohms | Compression | 1 | Beryllium Copper | Flange | Screw | Receptacle Male Pin | Threaded | ||
Radiall USA, Inc. | Gold | Stainless Steel | -65 ░C | 165 °C | 500 | Polytetrafluoroethylene (PTFE) | 500 V | 18 GHz | SMA | Silver | Extended Insulation | Panel Mount | 50 Ohms | Solder | 1 | Brass | Flange | Solder | Plug Male Pin | Threaded | |
 Radiall USA, Inc. | Gold | Stainless Steel | -65 ░C | 165 °C | 500 | Polytetrafluoroethylene (PTFE) | 500 V | 18 GHz | SMA | Silver | Extended Insulation | Panel Mount | 50 Ohms | Solder | 1 | Brass | Flange | Solder | Plug Male Pin | Threaded | |
 Radiall USA, Inc. | Gold | Stainless Steel | -65 ░C | 165 °C | 500 | Polytetrafluoroethylene (PTFE) | 500 V | 18 GHz | SMA | Silver | Panel Mount | 50 Ohms | Solder Cup | 1 | Brass | Flange | Solder | Plug Male Pin | Threaded | ||
 Radiall USA, Inc. | Gold | Stainless Steel | -65 ░C | 165 °C | 500 | Polytetrafluoroethylene (PTFE) | 500 V | Gold | 18 GHz | SMA | Gold | Panel Mount Through Hole | 50 Ohms | Solder Tab | 1 | Beryllium Copper | Flange | Solder | Plug Male Pin | Threaded | |
 Radiall USA, Inc. | Gold | Stainless Steel | -65 ░C | 165 °C | 500 | Polytetrafluoroethylene (PTFE) | 500 V | Gold | 18 GHz | SMA | Gold | Panel Mount | 50 Ohms | Solder Cup | 1 | Brass | Flange | Solder | Plug Male Pin | Threaded | |
Radiall USA, Inc. | Gold | Stainless Steel | -65 ░C | 105 ░C | 500 | Polytetrafluoroethylene (PTFE) | 500 V | 18 GHz | SMA | Silver | Panel Mount | 50 Ohms | Compression | 1 | Beryllium Copper | Flange | Screw | Receptacle Male Pin | Threaded | ||
 Radiall USA, Inc. | Gold | Stainless Steel | -65 ░C | 165 °C | 500 | Polytetrafluoroethylene (PTFE) | 500 V | Gold | 18 GHz | SMA | Gold | Extended Insulation | Panel Mount | 50 Ohms | Solder | 1 | Brass | Flange | Solder | Plug Male Pin | Threaded |
Radiall USA, Inc. | Gold | Stainless Steel | -65 ░C | 165 °C | 500 | Polytetrafluoroethylene (PTFE) | 500 V | Gold | 18 GHz | SMA | Gold | Panel Mount | 50 Ohms | Solder Cup | 1 | Brass | Flange | Solder | Plug Male Pin | Threaded |
