800-10 Series

Manufacturer: Mill-Max Manufacturing Corp.

Catalog

Catalog

CONN HEADER VERT 34POS 2.54MM

...

Part	Number of Rows	Contact Finish - Post	Mounting Type	Contact Length - Mating	Contact Length - Mating	Pitch - Mating	Pitch - Mating	Contact Length - Post	Contact Length - Post	Contact Shape	Contact Material	Contact Type	Number of Positions [custom]	Shrouding	Termination	Connector Type	Contact Finish - Mating	Fastening Type	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Insulation Material	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Overall Contact Length	Overall Contact Length	Insulation Color	Number of Positions Loaded	Number of Positions	Insulation Height	Insulation Height	Contact Length - Post [x]	Contact Length - Post [x]
Mill-Max Manufacturing Corp. 800-10-034-61-001000	1	Gold	Through Hole	4.85 mm	0.191 in	0.1 "	2.54 mm	0.104 in	2.64 mm	Circular	Brass Alloy	Male Pin	34	Unshrouded	Press-Fit Solder	Header	Gold	Push-Pull	10 Áin	0.25 çm	Polycyclohexylenedimethylene Terephthalate (PCT)	0.25 µm	10 µin	10.29 mm	0.405 in	Black	All
Mill-Max Manufacturing Corp. 800-10-040-30-001000	1	Gold	Surface Mount	4.95 mm	0.195 in	0.1 "	2.54 mm			Circular	Brass Alloy	Male Pin		Unshrouded	Solder	Header	Gold	Push-Pull	10 Áin	0.25 çm	Polycyclohexylenedimethylene Terephthalate (PCT)	0.25 µm	10 µin			Black	All	40
Mill-Max Manufacturing Corp. 800-10-021-61-001000	1	Gold	Through Hole	4.85 mm	0.191 in	0.1 "	2.54 mm	0.104 in	2.64 mm	Circular	Brass Alloy	Male Pin		Unshrouded	Press-Fit Solder	Header	Gold	Push-Pull	10 Áin	0.25 çm	Polycyclohexylenedimethylene Terephthalate (PCT)	0.25 µm	10 µin	10.29 mm	0.405 in	Black	All	21
Mill-Max Manufacturing Corp. 800-10-058-30-001000	1	Gold	Surface Mount	4.95 mm	0.195 in	0.1 "	2.54 mm			Circular	Brass Alloy	Male Pin		Unshrouded	Solder	Header	Gold	Push-Pull	10 Áin	0.25 çm	Polycyclohexylenedimethylene Terephthalate (PCT)	0.25 µm	10 µin			Black	All	58
Mill-Max Manufacturing Corp. 800-10-051-61-001000	1	Gold	Through Hole	4.85 mm	0.191 in	0.1 "	2.54 mm	0.104 in	2.64 mm	Circular	Brass Alloy	Male Pin		Unshrouded	Press-Fit Solder	Header	Gold	Push-Pull	10 Áin	0.25 çm	Polycyclohexylenedimethylene Terephthalate (PCT)	0.25 µm	10 µin	10.29 mm	0.405 in	Black	All	51
Mill-Max Manufacturing Corp. 800-10-011-10-002000	1	Gold	Through Hole	3.61 mm	0.142 in	0.1 "	2.54 mm	0.118 in	3 mm	Circular	Brass Alloy	Male Pin		Unshrouded	Solder	Header	Gold	Push-Pull	10 Áin	0.25 çm	Polycyclohexylenedimethylene Terephthalate (PCT)	0.25 µm	10 µin			Black	All	11
Mill-Max Manufacturing Corp. 800-10-030-10-004000	1	Gold	Through Hole	3.18 mm	0.125 in	0.1 "	2.54 mm	0.125 in	3.18 mm	Circular	Brass Alloy	Male Pin		Unshrouded	Solder	Header	Gold	Push-Pull	10 Áin	0.25 çm	Polycyclohexylenedimethylene Terephthalate (PCT)	0.25 µm	10 µin	8.38 mm	0.33 in	Black	All	30	1.8 mm	0.071 in
Mill-Max Manufacturing Corp. 800-10-014-20-001000	1	Gold	Right Angle Through Hole	4.95 mm	0.195 in	0.1 "	2.54 mm			Circular	Brass Alloy	Male Pin		Unshrouded	Solder	Header	Gold	Push-Pull	10 Áin	0.25 çm	Polycyclohexylenedimethylene Terephthalate (PCT)	0.25 µm	10 µin			Black	All	14	2.54 mm	0.1 in	0.126 "	3.2 mm
Mill-Max Manufacturing Corp. 800-10-048-10-001000	1	Gold	Through Hole	4.95 mm	0.195 in	0.1 "	2.54 mm	0.118 in	3 mm	Circular	Brass Alloy	Male Pin		Unshrouded	Solder	Header	Gold	Push-Pull	10 Áin	0.25 çm	Polycyclohexylenedimethylene Terephthalate (PCT)	0.25 µm	10 µin	11.12 mm	0.438 in	Black	All	48
Mill-Max Manufacturing Corp. 800-10-046-61-001000	1	Gold	Through Hole	4.85 mm	0.191 in	0.1 "	2.54 mm	0.104 in	2.64 mm	Circular	Brass Alloy	Male Pin		Unshrouded	Press-Fit Solder	Header	Gold	Push-Pull	10 Áin	0.25 çm	Polycyclohexylenedimethylene Terephthalate (PCT)	0.25 µm	10 µin	10.29 mm	0.405 in	Black	All	46
