MS3106F10 Series
Manufacturer: ITT Cannon, LLC
Beta
⌘K
CONN PLUG FMALE 2P SOLDER CUP
| Part | Operating Temperature [Min] | Operating Temperature [Max] | Primary Material | Number of Positions | Mounting Type | Shell Size - Insert | Fastening Type | Connector Type | Voltage Rating | Orientation | Current Rating (Amps) | Contact Finish - Mating | Features | Shell Finish | Qualification | Color | Grade | Shell Material | Ingress Protection | Contact Material | Insert Material | Shielding | Applications |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 ITT Cannon, LLC | -55 C | 125 °C | Metal | 2 | Free Hanging (In-Line) | 10SL-4 | Threaded | Plug Female Sockets | 500 VAC 700 VDC | N (Normal) | 22 A | Silver | Cable Clamp Coupling Nut | Olive Drab Cadmium | MIL-DTL-5015 | Olive Drab | Military | Aluminum Alloy | Environment Resistant | ||||
ITT Cannon, LLC | -55 C | 125 °C | Metal | 1 | Free Hanging (In-Line) | 10S-2 | Threaded | Plug Male Pins | N (Normal) | Silver | Backshell Coupling Nut | Olive Drab Cadmium | MIL-DTL-5015 | Olive Drab | Military | Aluminum Alloy | Environment Resistant | Copper Alloy | Plastic | Unshielded | Aviation Industrial Marine Military | ||
 ITT Cannon, LLC | -55 C | 125 °C | Metal | 2 | Free Hanging (In-Line) | 10SL-4 | Threaded | Plug Female Sockets | 500 VAC 700 VDC | N (Normal) | 22 A | Silver | Cable Clamp Coupling Nut | Olive Drab Cadmium | MIL-DTL-5015 | Olive Drab | Military | Aluminum Alloy | Environment Resistant | ||||
ITT Cannon, LLC | -55 C | 125 °C | Metal | 1 | Free Hanging (In-Line) | 10S-2 | Threaded | Plug Female Sockets | N (Normal) | Silver | Backshell Coupling Nut | Olive Drab Cadmium | MIL-DTL-5015 | Olive Drab | Military | Aluminum Alloy | Environment Resistant | Copper Alloy | Plastic | Unshielded | Aviation Industrial Marine Military |
