PMNF1 Series
Manufacturer: Panduit Corp
Beta
⌘K
RING TONGUE TERMINAL, M5, #10, 18 AWG, 1 MM², PMNF SERIES, RED
| Part | Termination | Wire Gauge [Max] | Wire Gauge [Min] | Length - Overall [x] | Length - Overall [x] | Thickness | Thickness | Insulation | Features | Width - Outer Edges [y] | Width - Outer Edges [y] | Insulation Diameter [Min] [diameter] | Insulation Diameter [Max] [diameter] | Insulation Diameter [Min] [diameter] | Insulation Diameter [Max] [diameter] | Contact Material | Mounting Type | Color | Contact Finish | Material - Insulation | Stud/Tab Size | Terminal Type | Insulation Diameter [diameter] | Insulation Diameter [diameter] | Tongue Inside Opening [x] | Tongue Inside Opening [x] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Panduit Corp | Crimp | 22 AWG | 17.5 AWG | 0.86 " | 21.84 mm | 0.81 mm | 0.032 in | Insulated | Serrated Termination | 8.89 mm | 0.35 in | 0.07 " | 3.45 mm | 1.78 mm | 0.136 " | Copper | Free Hanging (In-Line) | Red | Tin | Nylon Polyamide (PA) | M5 Stud | Circular | ||||
 Panduit Corp | Crimp | 22 AWG | 17.5 AWG | 0.79 in | 20.06 mm | Insulated | Serrated Termination | 5.9 mm | 0.232 in | Brass | Free Hanging (In-Line) | Red | Tin | Polyamide (PA66) Nylon 6/6 | M3 Stud | Standard | 0.146 in | 3.71 mm | 3.3 mm | 0.13 in |
