TSM-107 Series

Catalog

CONN HEADER SMD 14POS 2.54MM

...

Part	Number of Positions	Termination	Pitch - Mating	Pitch - Mating	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Style	Insulation Material	Number of Rows	Operating Temperature [Max]	Operating Temperature [Min]	Insulation Color	Connector Type	Material Flammability Rating	Contact Type	Number of Positions Loaded	Features	Contact Finish - Post	Contact Shape	Contact Material	Contact Length - Mating	Contact Length - Mating	Shrouding	Mounting Type	Fastening Type	Insulation Height	Insulation Height	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Contact Finish - Mating	Contact Length - Mating [x]	Number of Positions Loaded
Samtec Inc. TSM-107-02-T-DV-A-P	14	Solder	0.1 in	2.54 mm	2.54 mm	0.1 in	Board to Board Cable	Liquid Crystal Polymer (LCP)	2	105 ░C	-55 °C	Black	Cuttable Header	UL94 V-0	Male Pin	All	Board Guide Pick and Place	Tin	Square	Phosphor Bronze	8.13 mm	0.32 in	Unshrouded	Surface Mount	Push-Pull	0.1 in	2.54 mm
Samtec Inc. TSM-107-01-LM-DH-LC	14	Solder	0.1 in	2.54 mm	2.54 mm	0.1 in	Board to Board Cable	Liquid Crystal Polymer (LCP)	2	125 °C	-55 °C	Black	Header	UL94 V-0	Male Pin	All		Tin	Square	Phosphor Bronze	5.84 mm		Unshrouded	Surface Mount Right Angle	Push-Pull	0.24 in	6.1 mm	10 çin	0.25 çm	Gold	0.23 in
Samtec Inc. TSM-107-03-S-DH-006	14	Solder	0.1 in	2.54 mm	2.54 mm	0.1 in	Board to Board Cable	Liquid Crystal Polymer (LCP)	2	125 °C	-55 °C	Black	Header	UL94 V-0	Male Pin			Tin	Square	Phosphor Bronze	10.67 mm	0.42 in	Unshrouded	Surface Mount Right Angle	Push-Pull	0.24 in	6.1 mm	30 Áin	0.76 Ám	Gold		13
Samtec Inc. TSM-107-01-F-DV-006	14	Solder	0.1 in	2.54 mm	2.54 mm	0.1 in	Board to Board Cable	Liquid Crystal Polymer (LCP)	2	125 °C	-55 °C	Black	Cuttable Header	UL94 V-0	Male Pin			Tin	Square	Phosphor Bronze	5.84 mm		Unshrouded	Surface Mount	Push-Pull	0.1 in	2.54 mm	3 µin	0.076 µm	Gold	0.23 in	13
Samtec Inc. TSM-107-03-L-DV-P	14	Solder	0.1 in	2.54 mm	2.54 mm	0.1 in	Board to Board Cable	Liquid Crystal Polymer (LCP)	2	125 °C	-55 °C	Black	Cuttable Header	UL94 V-0	Male Pin	All	Pick and Place	Tin	Square	Phosphor Bronze	10.67 mm	0.42 in	Unshrouded	Surface Mount	Push-Pull	0.1 in	2.54 mm	10 çin	0.25 çm	Gold
Samtec Inc. TSM-107-01-S-DH-A-001-P	14	Solder	0.1 in	2.54 mm	2.54 mm	0.1 in	Board to Board Cable	Liquid Crystal Polymer (LCP)	2	125 °C	-55 °C	Black	Header	UL94 V-0	Male Pin		Board Guide Pick and Place	Tin	Square	Phosphor Bronze	5.84 mm		Unshrouded	Surface Mount Right Angle	Push-Pull	0.24 in	6.1 mm	30 Áin	0.76 Ám	Gold	0.23 in	13
Samtec Inc. TSM-107-01-SM-DV-P-TR	14	Solder	0.1 in	2.54 mm	2.54 mm	0.1 in	Board to Board Cable	Liquid Crystal Polymer (LCP)	2	125 °C	-55 °C	Black	Cuttable Header	UL94 V-0	Male Pin	All	Pick and Place	Tin	Square	Phosphor Bronze	5.84 mm		Unshrouded	Surface Mount	Push-Pull	0.1 in	2.54 mm	30 Áin	0.76 Ám	Gold	0.23 in
Samtec Inc. TSM-107-01-LM-DH	14	Solder	0.1 in	2.54 mm	2.54 mm	0.1 in	Board to Board Cable	Liquid Crystal Polymer (LCP)	2	125 °C	-55 °C	Black	Header	UL94 V-0	Male Pin	All		Tin	Square	Phosphor Bronze	5.84 mm		Unshrouded	Surface Mount Right Angle	Push-Pull	0.24 in	6.1 mm	10 çin	0.25 çm	Gold	0.23 in
Samtec Inc. TSM-107-04-L-SH-P-TR	7	Solder	0.1 in	2.54 mm			Board to Board Cable	Liquid Crystal Polymer (LCP)	1	125 °C	-55 °C	Black	Header	UL94 V-0	Male Pin	All	Pick and Place	Tin	Square	Phosphor Bronze	3.05 mm	0.12 in	Unshrouded	Surface Mount Right Angle	Push-Pull	0.12 in	3.05 mm	10 çin	0.25 çm	Gold
Samtec Inc. TSM-107-01-TM-DH-A	14	Solder	0.1 in	2.54 mm	2.54 mm	0.1 in	Board to Board Cable	Liquid Crystal Polymer (LCP)	2	105 ░C	-55 °C	Black	Header	UL94 V-0	Male Pin	All	Board Guide	Tin	Square	Phosphor Bronze	5.84 mm		Unshrouded	Surface Mount Right Angle	Push-Pull	0.24 in	6.1 mm				0.23 in
