794072 Series

Catalog

CONN WIRE TO BOARD HDR 24POWER POS 4.14MM SOLDER ST THRU-HOLE BAG

Part	Voltage Rating	Connector Type	Contact Material	Style	Termination	Number of Rows [custom]	Contact Finish Thickness - Post	Contact Shape	Pitch - Mating	Pitch - Mating	Contact Type	Applications	Shrouding	Number of Positions Loaded	Current Rating (Amps)	Insulation Color	Mounting Type	Contact Length - Post	Contact Length - Post	Features	Material Flammability Rating	Fastening Type	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Number of Positions	Operating Temperature [Min]	Operating Temperature [Max]	Contact Finish - Post	Insulation Height	Insulation Height	Insulation Material	Contact Finish - Mating	Row Spacing - Mating [x]	Row Spacing - Mating [x]
TE Connectivity AMP Connectors 794072-2	600 VAC	Header	Brass	Board to Cable/Wire	Solder	2	3.81 Ám	Circular	0.163 in	4.14 mm	Male Pin	General Purpose	Shrouded - 4 Wall	All	Varies by Wire Gauge	White	Through Hole	4.45 mm	0.175 in	Board Lock	UL94 V-0	Locking Ramp	0.76 Ám	30 Áin	24	-20 ░C	105 ░C	Tin-Lead	13.5 mm	0.531 in	Nylon Polyamide (PA)	Gold	4.14 mm	0.163 in
TE Connectivity AMP Connectors 794072-1	600 VAC	Header	Brass	Board to Cable/Wire	Solder	2	3.81 Ám	Circular	0.163 in	4.14 mm	Male Pin	General Purpose	Shrouded - 4 Wall	All	Varies by Wire Gauge	White	Through Hole	4.45 mm	0.175 in	Board Lock	UL94 V-0	Locking Ramp	3.81 Ám	150 Áin	24	-20 ░C	85 °C	Tin-Lead	13.5 mm	0.531 in	Nylon Polyamide (PA)	Tin-Lead	4.14 mm	0.163 in
