TMC2208 Series
Manufacturer: Analog Devices Inc./Maxim Integrated
Beta
⌘K
TMC2208 STEPPER DRIVER BOARD
| Part | Supplied Contents | Utilized IC / Part | Type | Contents | Interface | Package / Case | Technology | Step Resolution [Min] | Step Resolution [Max] | Applications | Motor Type - Stepper | Mounting Type | Operating Temperature [Min] | Operating Temperature [Max] | Voltage - Load [Max] | Voltage - Load [Min] | Supplier Device Package | Output Configuration | Current - Output | Voltage - Supply [Min] | Voltage - Supply [Max] | Function | Motor Type - AC, DC |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Analog Devices Inc./Maxim Integrated | Board(s) | TMC2208 | Power Management | Board(s) | |||||||||||||||||||
 Analog Devices Inc./Maxim Integrated | Board(s) | TMC2208 | Power Management | Board(s) | |||||||||||||||||||
 Analog Devices Inc./Maxim Integrated | Logic UART | 28-VFQFN Exposed Pad | Power MOSFET | 1 | 0.00390625 | General Purpose | Bipolar | Surface Mount | -40 C | 125 °C | 36 V | 5.5 V | 28-QFN (5x5) | Half Bridge (4) | 1.2 A | 5.5 V | 36 V | Driver - Fully Integrated Control and Power Stage | |||||
 Analog Devices Inc./Maxim Integrated | Board(s) | TMC2208 | Power Management | Board(s) | |||||||||||||||||||
 Analog Devices Inc./Maxim Integrated | 28-VFQFN Exposed Pad | Power MOSFET | 1 | 0.00390625 | General Purpose | Bipolar | Surface Mount | -40 C | 125 °C | 36 V | 5.5 V | 28-QFN (5x5) | Half Bridge (2) | 1.2 A | 5.5 V | 36 V | Driver - Fully Integrated Control and Power Stage | Brushed DC |
