CMLS041B Series
Manufacturer: Delta Electronics/Cyntec
Beta
⌘K
FIXED IND 100NH 15A 6 MOHM SMD
| Part | Height - Seated (Max) [Max] [z] | Height - Seated (Max) [Max] [z] | DC Resistance (DCR) [Max] | Shielding | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [x] | Size / Dimension [y] | Current - Saturation (Isat) | Tolerance | Mounting Type | Current Rating (Amps) | Inductance | Package / Case | Operating Temperature [Min] | Operating Temperature [Max] | Material - Core | Inductance Frequency - Test |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Delta Electronics/Cyntec | 1.2 mm | 0.047 " | 6 mOhm | Shielded | 0.165 in | 0.173 in | 4.4 mm | 4.2 mm | 21 A | 3 % | Surface Mount | 15 A | 100 nH | Nonstandard | -55 C | 125 °C | Metal | 100 kHz |
 Delta Electronics/Cyntec | 1.2 mm | 0.047 " | Shielded | 0.165 in | 0.173 in | 4.4 mm | 4.2 mm | 11 A | 3 % | Surface Mount | 6.5 A | 470 nH | Nonstandard | -55 C | 125 °C | Metal | 100 kHz |
