0467.500 Series

FUSE 32V V/FA LEAD FREE SLIM 0603.500A

Catalog

FUSE 32V V/FA LEAD FREE SLIM 0603.500A

Part	DC Cold Resistance	Response Time	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Voltage Rating - AC	Approval Agency	Mounting Type	Package / Case	Package / Case	Breaking Capacity @ Rated Voltage	Voltage Rating - DC	Fuse Type	Operating Temperature [Max]	Operating Temperature [Min]	Current Rating (Amps)	Melting I²t
LITTELFUSE 0467.500NR	0.187 Ohms	Fast Blow	1.6 mm	0.012 in	0.31 mm	0.063 "	0.032 in	0.81 mm	32 V	CSA UL	Surface Mount	1608 Metric	0603	50 A	32 V	Board Mount (Cartridge Style Excluded)	90 °C	-55 C	0.5 A	0.0087
LITTELFUSE 0467.500NRHF	0.187 Ohms	Fast Blow	1.6 mm	0.012 in	0.31 mm	0.063 "	0.032 in	0.81 mm	32 V	CSA UL	Surface Mount	1608 Metric	0603	50 A	32 V	Board Mount (Cartridge Style Excluded)	90 °C	-55 C	0.5 A	0.0087

Catalog

FUSE 32V V/FA LEAD FREE SLIM 0603.500A

Description

The 467 Series Fast-Acting SMF is an ultra small (0603 size) thin-film device designed for secondary protection of circuits used in space constrained applications such as hand-held portable electronic devices.This series is 100% lead-free and meets the requirements of the RoHS directive. New Halogen-Free 467 Series fuses are available–to order use the "HF" suffix. See Part Numbering section for additional information..
