6831 Series

Catalog

WIRE, HOOK UP, ECOGEN™ ECOWIRE® PLUS, 300V, MPPE, BLACK, 10 AWG, 4.92 MM², 1000 FT

Part	Conductor Material	Operating Temperature [Min]	Operating Temperature [Max]	Conductor Strand [custom]	Conductor Strand [custom]	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Length	Length	Cable Type	Wire Gauge	Jacket (Insulation) Material	Voltage	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Jacket Color	Length [x]	Length [x]
ALPHA WIRE 6831 BK001	Copper Bare	-40 C	110 °C	19	23 AWG	0.43 mm	0.017 "	304.8 m	1000 ft	Hook-Up	10 AWG	Polyphenylene Ether (PPE)	300 VDC	3.73 mm	0.147 "	Black
ALPHA WIRE 6831 YL001	Copper Bare	-40 C	110 °C	19	23 AWG	0.43 mm	0.017 "	304.8 m	1000 ft	Hook-Up	10 AWG	Polyphenylene Ether (PPE)	300 VDC	3.73 mm	0.147 "	Yellow
ALPHA WIRE 6831 BK005	Copper Bare	-40 C	110 °C	19	23 AWG	0.43 mm	0.017 "			Hook-Up	10 AWG	Polyphenylene Ether (PPE)	300 VDC	3.73 mm	0.147 "	Black	100 ft	30.5 m
ALPHA WIRE 6831 GY005	Copper Bare	-40 C	110 °C	19	23 AWG	0.43 mm	0.017 "			Hook-Up	10 AWG	Polyphenylene Ether (PPE)	300 VDC	3.73 mm	0.147 "	Green Yellow Stripe	100 ft	30.5 m
ALPHA WIRE 6831 BR005	Copper Bare	-40 C	110 °C	19	23 AWG	0.43 mm	0.017 "			Hook-Up	10 AWG	Polyphenylene Ether (PPE)	300 VDC	3.73 mm	0.147 "	Brown	100 ft	30.5 m
ALPHA WIRE 6831 RD005	Copper Bare	-40 C	110 °C	19	23 AWG	0.43 mm	0.017 "			Hook-Up	10 AWG	Polyphenylene Ether (PPE)	300 VDC	3.73 mm	0.147 "	Red	100 ft	30.5 m
ALPHA WIRE 6831 OR005	Copper Bare	-40 C	110 °C	19	23 AWG	0.43 mm	0.017 "			Hook-Up	10 AWG	Polyphenylene Ether (PPE)	300 VDC	3.73 mm	0.147 "	Orange	100 ft	30.5 m
ALPHA WIRE 6831 YL005	Copper Bare	-40 C	110 °C	19	23 AWG	0.43 mm	0.017 "			Hook-Up	10 AWG	Polyphenylene Ether (PPE)	300 VDC	3.73 mm	0.147 "	Yellow	100 ft	30.5 m
ALPHA WIRE 6831 WH005	Copper Bare	-40 C	110 °C	19	23 AWG	0.43 mm	0.017 "			Hook-Up	10 AWG	Polyphenylene Ether (PPE)	300 VDC	3.73 mm	0.147 "	White	100 ft	30.5 m
ALPHA WIRE 6831 RD001	Copper Bare	-40 C	110 °C	19	23 AWG	0.43 mm	0.017 "	304.8 m	1000 ft	Hook-Up	10 AWG	Polyphenylene Ether (PPE)	300 VDC	3.73 mm	0.147 "	Red
