842-022 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 22POS 0.100
| Part | Material - Insulation | Termination Rows | Read Out | Number of Positions | Gender | Operating Temperature [Max] | Operating Temperature [Min] | Number of Rows | Number of Positions/Bay/Row | Color | Card Type | Mounting Type | Card Thickness [Max] | Card Thickness [Min] | Contact Finish | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Contact Finish Thickness | Contact Finish Thickness | Termination | Contact Type | Pitch | Pitch | Contact Material | Termination Rows [custom] | Number of Rows [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Single | 22 | Female | 125 °C | -40 C | 1 | 22 | Green | Non Specified - Single Edge | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | 0.25 Ám | 10 Áin | Wire Wrap | Cantilever | 0.1 " | 2.54 mm | Copper Alloy | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | Dual | 22 | Female | 125 °C | -40 C | 11 | Green | Non Specified - Dual Edge | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 4-40 Flush Mount Threaded Insert Top Opening | 0.25 Ám | 10 Áin | Solder | Cantilever | 0.1 " | 2.54 mm | Copper Alloy | 2 | 2 | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Single | 22 | Female | 125 °C | -40 C | 1 | 22 | Green | Non Specified - Single Edge | Right Angle Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | 0.25 Ám | 10 Áin | Solder | Cantilever | 0.1 " | 2.54 mm | Copper Alloy | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Single | 22 | Female | 125 °C | -40 C | 1 | 22 | Green | Non Specified - Single Edge | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 0.25 Ám | 10 Áin | Solder | Cantilever | 0.1 " | 2.54 mm | Copper Alloy | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Single | 22 | Female | 125 °C | -40 C | 1 | 22 | Green | Non Specified - Single Edge | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | 0.25 Ám | 10 Áin | Wire Wrap | Cantilever | 0.1 " | 2.54 mm | Copper Alloy | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | Dual | 22 | Female | 125 °C | -40 C | 11 | Green | Non Specified - Dual Edge | Right Angle Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Flush Mount M3 Threaded Insert Top Opening | 0.25 Ám | 10 Áin | Solder | Cantilever | 0.1 " | 2.54 mm | Copper Alloy | 2 | 2 | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Single | 22 | Female | 125 °C | -40 C | 1 | 22 | Green | Non Specified - Single Edge | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | 0.25 Ám | 10 Áin | Solder | Cantilever | 0.1 " | 2.54 mm | Copper Alloy | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | Dual | 22 | Female | 125 °C | -40 C | 11 | Green | Non Specified - Dual Edge | Right Angle Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | 0.25 Ám | 10 Áin | Solder | Cantilever | 0.1 " | 2.54 mm | Copper Alloy | 2 | 2 | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | Dual | 22 | Female | 125 °C | -40 C | 11 | Green | Non Specified - Dual Edge | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | 0.25 Ám | 10 Áin | Wire Wrap | Cantilever | 0.1 " | 2.54 mm | Copper Alloy | 2 | 2 | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | Dual | 22 | Female | 125 °C | -40 C | 11 | Green | Non Specified - Dual Edge | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Flush Mount M3 Threaded Insert Top Opening | 0.25 Ám | 10 Áin | Wire Wrap | Cantilever | 0.1 " | 2.54 mm | Copper Alloy | 2 | 2 |
