164A182 Series
Manufacturer: Amphenol CONEC
Beta
⌘K
CONN D-SUB HD RCPT 26P R/A SLDR
| Part | Number of Rows | Current Rating (Amps) | Number of Positions | Color | Dielectric Material | Material Flammability Rating | Connector Style | Contact Material | Shell Size, Connector Layout | Shell Size, Connector Layout | Termination | Operating Temperature [Min] | Operating Temperature [Max] | Voltage Rating | Contact Finish | Connector Type | Mounting Type | Contact Type | Flange Feature | Backset Spacing | Backset Spacing | Contact Finish Thickness | Contact Finish Thickness | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Amphenol CONEC | 3 | 3 A | 26 | Black | Polybutylene Terephthalate (PBT) Glass Filled | UL94 V-0 | D-Sub High Density | Copper Alloy | 2 | (DA A) High Density | Solder | -55 °C | 125 °C | 60 VDC | Gold | Receptacle Female Sockets | Board Edge Right Angle Through Hole | Signal | 4-40 | 0.314 in | 7.98 mm | 8 çin | 0.203 çm | |||
 Amphenol CONEC | 3 | 3 A | 62 | Black | Polybutylene Terephthalate (PBT) Glass Filled | UL94 V-0 | D-Sub High Density | Copper Alloy | 4 | Solder | -55 °C | 125 °C | 60 VDC | Gold | Receptacle Female Sockets | Board Edge Right Angle Through Hole | Signal | Housing/Shell (4-40) | 0.314 in | 7.98 mm | 8 çin | 0.203 çm | ||||
Amphenol CONEC | 3 | 3 A | 26 | Black | Polybutylene Terephthalate (PBT) Glass Filled | UL94 V-0 | D-Sub High Density | Copper Alloy | 2 | (DA A) High Density | Solder | -55 °C | 125 °C | 60 VDC | Gold | Receptacle Female Sockets | Board Edge Right Angle Through Hole | Signal | Housing/Shell (M3) | 0.314 in | 7.98 mm | 8 çin | 0.203 çm | |||
Amphenol CONEC | 3 | 3 A | 62 | Black | Polybutylene Terephthalate (PBT) Glass Filled | UL94 V-0 | D-Sub High Density | Copper Alloy | 4 | Solder | -55 °C | 125 °C | 60 VDC | Gold | Receptacle Female Sockets | Board Edge Right Angle Through Hole | Signal | Housing/Shell (M3) | 0.314 in | 7.98 mm | 8 çin | 0.203 çm | ||||
Amphenol CONEC | 3 | 3 A | 15 | Black | Polybutylene Terephthalate (PBT) Glass Filled | UL94 V-0 | D-Sub High Density | Copper Alloy | Solder | -55 °C | 125 °C | 60 VDC | Gold | Receptacle Female Sockets | Board Edge Right Angle Through Hole | Signal | 4-40 | 0.314 in | 7.98 mm | 8 çin | 0.203 çm | DE E | 1 | High Density |
