EEA-GA1 Series

Manufacturer: Panasonic Electronic Components

Catalog

CAP ALUM 15UF 20% 35V RADIAL TH

Part	Voltage - Rated	Lead Spacing	Lead Spacing	Capacitance	Package / Case	Operating Temperature [Min]	Operating Temperature [Max]	Lifetime @ Temp.	Ripple Current @ Low Frequency	Tolerance	Ripple Current @ High Frequency	Size / Dimension [diameter]	Size / Dimension [diameter]	Applications	Mounting Type	Polarization	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]
Panasonic Electronic Components EEA-GA1V150H	35 V	2.5 mm	0.098 in	15 µF	Can Radial	-55 C	105 ░C	1000 Hrs	50 mA	20 %	77.5 mA	0.248 "	6.3 mm	General Purpose	Through Hole	Polar	0.276 in	7 mm
Panasonic Electronic Components EEA-GA1HR15B	50 VDC	5 mm	0.197 "	0.15 ÁF	Can Radial	-55 C	105 ░C	1000 Hrs	1.7 mA	20 %	2.635 mA	0.157 in	4 mm	General Purpose	Through Hole	Polar	0.276 in	7 mm
Panasonic Electronic Components EEA-GA1H3R3	50 VDC	1.5 mm	0.059 in	3.3 µF	Can Radial	-55 C	105 ░C	1000 Hrs	22 mA	20 %	34.1 mA	0.157 in	4 mm	General Purpose	Through Hole	Polar	0.276 in	7 mm
Panasonic Electronic Components EEA-GA1V470B	35 V	5 mm	0.197 "	47 µF	Can Radial	-55 C	105 ░C	1000 Hrs	96 mA	20 %	148.8 mA	0.315 in	8 mm	General Purpose	Through Hole	Polar	0.276 in	7 mm
Panasonic Electronic Components EEA-GA1HR33	50 VDC	1.5 mm	0.059 in	0.33 µF	Can Radial	-55 C	105 ░C	1000 Hrs	3.5 mA	20 %		0.157 in	4 mm	General Purpose	Through Hole	Polar	0.276 in	7 mm
Panasonic Electronic Components EEA-GA1HR22H	50 VDC	2.5 mm	0.098 in	0.22 µF	Can Radial	-55 C	105 ░C	1000 Hrs	2.3 mA	20 %	3.565 mA	0.157 in	4 mm	General Purpose	Through Hole	Polar	0.276 in	7 mm
Panasonic Electronic Components EEA-GA1HR33B	50 VDC	5 mm	0.197 "	0.33 µF	Can Radial	-55 C	105 ░C	1000 Hrs	3.5 mA	20 %		0.157 in	4 mm	General Purpose	Through Hole	Polar	0.276 in	7 mm
Panasonic Electronic Components EEA-GA1H4R7H	50 VDC	1.5 mm	0.059 in	4.7 µF	Can Radial	-55 C	105 ░C	1000 Hrs	26 mA	20 %	40.3 mA	0.157 in	4 mm	General Purpose	Through Hole	Polar	0.276 in	7 mm
Panasonic Electronic Components EEA-GA1HR68	50 VDC	1.5 mm	0.059 in	0.68 µF	Can Radial	-55 C	105 ░C	1000 Hrs	7 mA	20 %	10.85 mA	0.157 in	4 mm	General Purpose	Through Hole	Polar	0.276 in	7 mm
Panasonic Electronic Components EEA-GA1E100	25 VDC	1.5 mm	0.059 in	10 µF	Can Radial	-55 C	105 ░C	1000 Hrs	33 mA	20 %	51.15 mA	0.157 in	4 mm	General Purpose	Through Hole	Polar	0.276 in	7 mm
