D3SH Series
Manufacturer: Omron Electronics Inc-EMC Div
Beta
⌘K
SWITCH DETECT SPST-NO 0.001A 5V
| Part | Mechanical Life | Features | Termination Style | Operating Force | Circuit | Operating Temperature [Min] | Operating Temperature [Max] | Switch Function | Voltage Rating - DC | Mounting Type | Electrical Life | Current Rating (Amps) | Operating Position | Operating Position | Actuator Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Omron Electronics Inc-EMC Div | 150000 Cycles | Left Operating Lever | SMD (SMT) Tab | 24 gf | SPST-NO | -25 °C | 85 °C | Off-Mom | 5 V | Surface Mount Right Angle | 100000 Cycles | 1 mA | 5.4 mm | 0.213 in | Angled Toggle (Detector) |
 Omron Electronics Inc-EMC Div | 150000 Cycles | Left Operating Lever | SMD (SMT) Tab | 31 gf | SPST-NC | -25 °C | 85 °C | On-Mom | 5 V | Surface Mount Right Angle | 100000 Cycles | 1 mA | 5 mm | 0.197 in | Angled Toggle (Detector) |
 Omron Electronics Inc-EMC Div | 150000 Cycles | Right Operating Lever | SMD (SMT) Tab | 24 gf | SPST-NC | -25 °C | 85 °C | On-Mom | 5 V | Surface Mount Right Angle | 100000 Cycles | 1 mA | 5.4 mm | 0.213 in | Angled Toggle (Detector) |
Omron Electronics Inc-EMC Div | 150000 Cycles | Right Operating Lever | SMD (SMT) Tab | 24 gf | SPST-NO | -25 °C | 85 °C | Off-Mom | 5 V | Surface Mount Right Angle | 100000 Cycles | 1 mA | 5.4 mm | 0.213 in | Angled Toggle (Detector) |
 Omron Electronics Inc-EMC Div | 150000 Cycles | Board Guide Left Operating Lever | SMD (SMT) Tab | 24 gf | SPST-NO | -25 °C | 85 °C | Off-Mom | 5 V | Surface Mount Right Angle | 100000 Cycles | 1 mA | 5.4 mm | 0.213 in | Angled Toggle (Detector) |
 Omron Electronics Inc-EMC Div | 150000 Cycles | Board Guide Right Operating Lever | SMD (SMT) Tab | 31 gf | SPST-NC | -25 °C | 85 °C | On-Mom | 5 V | Surface Mount Right Angle | 100000 Cycles | 1 mA | 5 mm | 0.197 in | Angled Toggle (Detector) |
Omron Electronics Inc-EMC Div | 150000 Cycles | Board Guide Left Operating Lever | SMD (SMT) Tab | 31 gf | SPST-NC | -25 °C | 85 °C | On-Mom | 5 V | Surface Mount Right Angle | 100000 Cycles | 1 mA | 5 mm | 0.197 in | Angled Toggle (Detector) |
Omron Electronics Inc-EMC Div | 150000 Cycles | Board Guide Right Operating Lever | SMD (SMT) Tab | 31 gf | SPST-NO | -25 °C | 85 °C | Off-Mom | 5 V | Surface Mount Right Angle | 100000 Cycles | 1 mA | 5 mm | 0.197 in | Angled Toggle (Detector) |
 Omron Electronics Inc-EMC Div | 150000 Cycles | Right Operating Lever | SMD (SMT) Tab | 31 gf | SPST-NO | -25 °C | 85 °C | Off-Mom | 5 V | Surface Mount Right Angle | 100000 Cycles | 1 mA | 5 mm | 0.197 in | Angled Toggle (Detector) |
