MB2511S Series
Manufacturer: NKK Switches
Beta
⌘K
SWITCH PUSHBUTTON SPDT 0.4VA 28V
| Part | Mechanical Life | Electrical Life | Actuator Marking | Voltage Rating - DC | Type | Circuit | Operating Temperature [Max] | Operating Temperature [Min] | Voltage Rating - AC | Current Rating (Amps) | Termination Style | Actuator Type | Switch Function | Mounting Type | Features | Panel Cutout Dimensions [diameter] | Color - Actuator/Cap |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NKK Switches | 200000 Cycles | 100000 Cycles | No Marking | 28 V | Standard | SPDT | 85 °C | -30 ░C | 28 V | 0.4 VA | PC Pin | Plunger for Cap | On-Mom | Right Angle Through Hole Vertical | Epoxy Sealed Terminals | ||
 NKK Switches | 200000 Cycles | 100000 Cycles | No Marking | 28 V | Standard | SPDT | 85 °C | -30 ░C | 28 V | 0.4 VA | Solder Lug | Plunger for Cap | On-Mom | Panel Mount Rear | Epoxy Sealed Terminals | 6.5 mm | |
 NKK Switches | 200000 Cycles | 100000 Cycles | No Marking | 28 V | Standard | SPDT | 85 °C | -30 ░C | 28 V | 0.4 VA | PC Pin | Plunger for Cap | On-Mom | Through Hole | Epoxy Sealed Terminals | ||
 NKK Switches | 200000 Cycles | 100000 Cycles | No Marking | 28 V | Standard | SPDT | 85 °C | -30 ░C | 28 V | 0.4 VA | PC Pin | Plunger for Cap | On-Mom | Panel Mount Rear | Epoxy Sealed Terminals | 6.5 mm | |
NKK Switches | 200000 Cycles | 25000 Steps | No Marking | Standard | SPDT | 85 °C | -30 ░C | 125 V | 3 A | Solder Lug | Button Round | On-Mom | Panel Mount Rear | Epoxy Sealed Terminals | 6.5 mm | Black | |
NKK Switches | 200000 Cycles | 100000 Cycles | No Marking | 28 V | Standard | SPDT | 85 °C | -30 ░C | 28 V | 0.4 VA | Solder Lug | Button Round | On-Mom | Panel Mount Rear | Epoxy Sealed Terminals | 6.5 mm | Red |
NKK Switches | 200000 Cycles | 25000 Steps | No Marking | Standard | SPDT | 85 °C | -30 ░C | 125 V | 3 A | Solder Lug | Button Round | On-Mom | Panel Mount Rear | Epoxy Sealed Terminals | 6.5 mm | White | |
 NKK Switches | 200000 Cycles | 100000 Cycles | No Marking | 28 V | Standard | SPDT | 85 °C | -30 ░C | 28 V | 0.4 VA | Solder Lug | Button Round | On-Mom | Panel Mount Rear | Epoxy Sealed Terminals | 6.5 mm | Black |
 NKK Switches | 200000 Cycles | 25000 Steps | No Marking | Standard | SPDT | 85 °C | -30 ░C | 125 V | 3 A | Solder Lug | Plunger for Cap | On-Mom | Panel Mount Rear | Epoxy Sealed Terminals | 6.5 mm | ||
NKK Switches | 200000 Cycles | 100000 Cycles | No Marking | 28 V | Standard | SPDT | 85 °C | -30 ░C | 28 V | 0.4 VA | PC Pin | Button Round | On-Mom | Through Hole | Epoxy Sealed Terminals | Black |
