2029151 Series
Manufacturer: TE Connectivity Raychem Cable Protection
Beta
⌘K
CONN HEADER R/A 4POS 4.2MM
| Part | Applications | Number of Positions Loaded | Insulation Material | Contact Material | Contact Shape | Number of Rows | Material Flammability Rating | Contact Finish - Post | Contact Length - Post | Contact Length - Post | Current Rating (Amps) | Termination | Shrouding | Style | Connector Type | Operating Temperature [Min] | Operating Temperature [Max] | Contact Type | Pitch - Mating | Pitch - Mating | Fastening Type | Number of Positions | Voltage Rating | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
TE Connectivity Raychem Cable Protection | General Purpose Industrial Lighting | All | Nylon Polyamide (PA) | Brass | Square | 1 | UL94 V-0 | Tin | 3.5 mm | 0.138 in | 9 A | Solder | Shrouded - 4 Wall | Board to Cable/Wire | Header | -40 °C | 105 ░C | Male Pin | 4.2 mm | 0.165 in | Locking Ramp | 4 | 600 VAC | Through Hole Right Angle |
 TE Connectivity Raychem Cable Protection | General Purpose Industrial Lighting | All | Nylon Polyamide (PA) | Brass | Square | 1 | UL94 V-0 | Tin | 3.5 mm | 0.138 in | 9 A | Solder | Shrouded - 4 Wall | Board to Cable/Wire | Header | -40 °C | 105 ░C | Male Pin | 4.2 mm | 0.165 in | Locking Ramp | 600 VAC | Through Hole Right Angle |
