G80YBR-P Series
Manufacturer: ODU
Beta
⌘K
AMC RECEPTACLE, SZ.0, STY.8, 10P
| Part | Shell Finish | Connector Type | Shielding | Voltage Rating | Primary Material | Applications | Number of Positions | Shell Material | Contact Material | Material Flammability Rating | Insert Material | Current Rating (Amps) | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Ingress Protection | Contact Finish - Mating | Mounting Feature | Operating Temperature [Min] | Operating Temperature [Max] | Color | Fastening Type | Shell Size - Insert [custom] | Orientation | Mounting Type | Termination |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Ruthenium over Electroless Nickel | Receptacle Female Sockets | Shielded | 200 V | Metal | Industrial Medical Military | 10 | Aluminum | Copper Alloy | UL94 V-0 | Polyetheretherketone (PEEK) | 5 A | 50 µin | 1.27 µm | IP68 IP69K | Gold | Bulkhead - Front Side Nut | -51 °C | 125 °C | Silver | Detent Lock Push-Pull | 0 | B | Panel Mount | ||
Ruthenium over Electroless Nickel | Receptacle Female Sockets | Shielded | 200 V | Metal | Industrial Medical Military | 9 | Aluminum | Copper Alloy | UL94 V-0 | Polyetheretherketone (PEEK) | 5 A | 50 µin | 1.27 µm | IP68 IP69K | Gold | Bulkhead - Front Side Nut | -51 °C | 125 °C | Silver | Detent Lock Push-Pull | 0 | B | Panel Mount Through Hole | Solder | |
Ruthenium over Electroless Nickel | Receptacle Female Sockets | Shielded | 300 VDC | Metal | Industrial Medical Military | 4 | Aluminum | Copper Alloy | UL94 V-0 | Polyetheretherketone (PEEK) | 5 A | 50 µin | 1.27 µm | IP68 IP69K | Gold | Bulkhead - Front Side Nut | -51 °C | 125 °C | Silver | Detent Lock Push-Pull | 0 | B | Panel Mount Through Hole | Solder | |
Ruthenium over Electroless Nickel | Receptacle Female Sockets | Shielded | 300 VDC | Metal | Industrial Medical Military | 7 | Aluminum | Copper Alloy | UL94 V-0 | Polyetheretherketone (PEEK) | 2 A | 50 µin | 1.27 µm | IP68 IP69K | Gold | Bulkhead - Front Side Nut | -51 °C | 125 °C | Silver | Detent Lock Push-Pull | 0 | B | Panel Mount | ||
Ruthenium over Electroless Nickel | Receptacle Female Sockets | Shielded | 300 VDC | Metal | Industrial Medical Military | 4 | Aluminum | Copper Alloy | UL94 V-0 | Polyetheretherketone (PEEK) | 7 A | 50 µin | 1.27 µm | IP68 IP69K | Gold | Bulkhead - Front Side Nut | -51 °C | 125 °C | Silver | Detent Lock Push-Pull | 0 | B | Panel Mount | ||
Ruthenium over Electroless Nickel | Receptacle Female Sockets | Shielded | 300 VDC | Metal | Industrial Medical Military | 7 | Aluminum | Copper Alloy | UL94 V-0 | Polyetheretherketone (PEEK) | 5 A | 50 µin | 1.27 µm | IP68 IP69K | Gold | Bulkhead - Front Side Nut | -51 °C | 125 °C | Silver | Detent Lock Push-Pull | 0 | B | Panel Mount Through Hole | Solder | |
Ruthenium over Electroless Nickel | Receptacle Female Sockets | Shielded | 200 V | Metal | Industrial Medical Military | 10 | Aluminum | Copper Alloy | UL94 V-0 | Polyetheretherketone (PEEK) | 5 A | 50 µin | 1.27 µm | IP68 IP69K | Gold | Bulkhead - Front Side Nut | -51 °C | 125 °C | Silver | Detent Lock Push-Pull | 0 | B | Panel Mount Through Hole | Solder | |
Ruthenium over Electroless Nickel | Receptacle Female Sockets | Shielded | 300 VDC | Metal | Industrial Medical Military | 7 | Aluminum | Copper Alloy | UL94 V-0 | Polyetheretherketone (PEEK) | 5 A | 50 µin | 1.27 µm | IP68 IP69K | Gold | Bulkhead - Front Side Nut | -51 °C | 125 °C | Silver | Detent Lock Push-Pull | 0 | B | Panel Mount |
