FGA.0B Series
Manufacturer: LEMO
Beta
⌘K
CONN PLUG MALE 7P GOLD SLDR CUP
| Part | Primary Material | Cable Opening [Max] | Cable Opening [Max] | Cable Opening [Min] | Cable Opening [Min] | Number of Positions | Contact Finish - Mating | Operating Temperature [Min] | Operating Temperature [Max] | Fastening Type | Contact Material | Backshell Material, Plating | Orientation | Shell Size - Insert [custom] | Connector Type | Current Rating (Amps) | Features | Material Flammability Rating | Ingress Protection | Shell Finish | Shielding | Insert Material | Color | Mounting Type | Contact Finish Thickness - Mating [custom] | Contact Finish Thickness - Mating [custom] | Shell Material | Shell Size - Insert | Cable Opening [Min] | Cable Opening [Max] | Termination |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Metal | 4.2 mm | 0.165 " | 0.126 " | 3.2 mm | 7 | Gold | -55 C | 250 °C | Push-Pull | Brass | Brass Chrome | A | 307 | Plug Male Pins | 2.5 A | Backshell | UL94 V-0 | IP50 - Dust Protected | Chrome | Shielded | Polyetheretherketone (PEEK) | Silver | Free Hanging (In-Line) | 39.4 µin | 1 µm | Brass | |||||
Metal | 4 | Gold | -55 C | 250 °C | Push-Pull | Brass | Brass Chrome | A | Plug Male Pins | 7 A | Backshell | UL94 V-0 | IP50 - Dust Protected | Chrome | Shielded | Polyetheretherketone (PEEK) | Silver | Free Hanging (In-Line) | 39.4 µin | 1 µm | Brass | 304 | 0.091 in 2.3 mm | 0.126 in 3.2 mm | |||||||
Metal | 5.2 mm | 4.2 mm | 5 | Gold | -55 C | 250 °C | Push-Pull | Brass | Brass Chrome | A | Plug Male Pins | 6.5 A | Backshell | UL94 V-0 | IP50 - Dust Protected | Chrome | Shielded | Polyetheretherketone (PEEK) | Silver | Free Hanging (In-Line) | 39.4 µin | 1 µm | Brass | 305 | 0.165 " | 0.205 in | Crimp | ||||
Metal | 5.2 mm | 4.2 mm | 2 | Gold | -55 C | 250 °C | Push-Pull | Brass | Brass Chrome | A | Plug Male Pins | 10 A | Backshell | UL94 V-0 | IP50 - Dust Protected | Chrome | Shielded | Polyetheretherketone (PEEK) | Silver | Free Hanging (In-Line) | 39.4 µin | 1 µm | Brass | 302 | 0.165 " | 0.205 in | |||||
Metal | 4.2 mm | 0.165 " | 0.126 " | 3.2 mm | 5 | Gold | -55 C | 250 °C | Push-Pull | Brass | Brass Chrome | A | Plug Male Pins | 6.5 A | Backshell | UL94 V-0 | IP50 - Dust Protected | Chrome | Shielded | Polyetheretherketone (PEEK) | Silver | Free Hanging (In-Line) | 39.4 µin | 1 µm | Brass | 305 | |||||
Metal | Gold | -55 C | 250 °C | Push-Pull | Brass | Brass Chrome | A | Plug Male Pins | 8 A | Backshell | UL94 V-0 | IP50 - Dust Protected | Chrome | Shielded | Polyetheretherketone (PEEK) | Silver | Free Hanging (In-Line) | 39.4 µin | 1 µm | Brass | 303 | 0.091 in 2.3 mm | 0.126 in 3.2 mm | ||||||||
Metal | 4.2 mm | 0.165 " | 0.126 " | 3.2 mm | 6 | Gold | -55 C | 250 °C | Push-Pull | Brass | Brass Chrome | A | Plug Male Pins | 2.5 A | Backshell | UL94 V-0 | IP50 - Dust Protected | Chrome | Shielded | Polyetheretherketone (PEEK) | Silver | Free Hanging (In-Line) | 39.4 µin | 1 µm | Brass | 306 | |||||
Metal | 5.2 mm | 4.2 mm | 6 | Gold | -55 C | 250 °C | Push-Pull | Brass | Brass Chrome | A | Plug Male Pins | 2.5 A | Backshell | UL94 V-0 | IP50 - Dust Protected | Chrome | Shielded | Polyetheretherketone (PEEK) | Silver | Free Hanging (In-Line) | 39.4 µin | 1 µm | Brass | 306 | 0.165 " | 0.205 in | Crimp | ||||
Metal | 5.2 mm | 4.2 mm | 9 | Gold | -55 C | 250 °C | Push-Pull | Brass | Brass Chrome | A | Plug Male Pins | 2 A | Backshell | UL94 V-0 | IP50 - Dust Protected | Chrome | Shielded | Polyetheretherketone (PEEK) | Silver | Free Hanging (In-Line) | 39.4 µin | 1 µm | Brass | 309 | 0.165 " | 0.205 in | Crimp | ||||
Metal | 5.6 mm | 5.3 mm | 5 | Gold | -55 C | 250 °C | Push-Pull | Brass | Brass Chrome | A | Plug Male Pins | 6.5 A | Backshell | UL94 V-0 | IP50 - Dust Protected | Chrome | Shielded | Polyetheretherketone (PEEK) | Silver | Free Hanging (In-Line) | 39.4 µin | 1 µm | Brass | 305 | 0.209 in | 0.22 in | Crimp |
