ECC10 Series
Manufacturer: Sullins Connector Solutions
Catalog
CONN EDGE DUAL FMALE 20POS 0.100
...
| Part | Card Type | Contact Finish Thickness | Contact Finish Thickness | Termination | Pitch [x] | Pitch [x] | Mounting Type | Card Thickness | Card Thickness | Gender | Read Out | Operating Temperature [Max] | Operating Temperature [Min] | Number of Positions/Bay/Row [custom] | Features | Number of Positions | Material - Insulation | Number of Rows | Color | Contact Finish | Contact Material | Flange Feature | Contact Type | Flange Feature [diameter] | Flange Feature [diameter] | Flange Feature | Flange Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Sullins Connector Solutions | Non Specified - Dual Edge | 0.76 Ám | 30 Áin | Press-Fit | 2.54 mm | 0.1 in | Through Hole | 0.062 in | 1.57 mm | Female | Dual | 125 °C | -65 ░C | 10 | Open Card Slot | 20 | Polybutylene Terephthalate (PBT) | 2 | Black | Gold | Phosphor Bronze | ||||||
Sullins Connector Solutions | Non Specified - Dual Edge | 0.76 Ám | 30 Áin | Solder | 2.54 mm | 0.1 in | Through Hole Right Angle | 0.062 in | 1.57 mm | Female | Dual | 125 °C | -65 ░C | 10 | 20 | Polybutylene Terephthalate (PBT) | 2 | Gold | Phosphor Bronze | 4-40 Flush Mount Threaded Insert Top Opening | Hairpin Bellows | ||||||
Sullins Connector Solutions | Non Specified - Dual Edge | 0.76 Ám | 30 Áin | Solder | 2.54 mm | 0.1 in | Through Hole | 0.062 in | 1.57 mm | Female | Dual | 125 °C | -65 ░C | 10 | 20 | Polybutylene Terephthalate (PBT) | 2 | Gold | Phosphor Bronze | Cantilever | |||||||
Sullins Connector Solutions | Non Specified - Dual Edge | 0.76 Ám | 30 Áin | Solder | 2.54 mm | 0.1 in | Board Edge Straddle Mount | 0.062 in | 1.57 mm | Female | Dual | 125 °C | -65 ░C | 10 | Card Extender | 20 | Polybutylene Terephthalate (PBT) | 2 | Gold | Phosphor Bronze | Side Mount Opening Unthreaded | Loop Bellows | 0.125 in | 3.18 mm | |||
 Sullins Connector Solutions | Non Specified - Dual Edge | 0.76 Ám | 30 Áin | Solder | 2.54 mm | 0.1 in | Board Edge Straddle Mount | 0.062 in | 1.57 mm | Female | Dual | 125 °C | -65 ░C | 10 | Card Extender | 20 | Polybutylene Terephthalate (PBT) | 2 | Gold | Phosphor Bronze | Side Mount Opening Unthreaded | Hairpin Bellows | 0.125 in | 3.18 mm | |||
Sullins Connector Solutions | Non Specified - Dual Edge | 0.76 Ám | 30 Áin | Solder | 2.54 mm | 0.1 in | Through Hole | 0.093 in | 2.36 mm | Female | Dual | 125 °C | -65 ░C | 10 | 20 | Polybutylene Terephthalate (PBT) | 2 | Blue | Gold | Phosphor Bronze | Full Bellows | ||||||
Sullins Connector Solutions | Non Specified - Dual Edge | 0.76 Ám | 30 Áin | Solder | 2.54 mm | 0.1 in | Board Edge Straddle Mount | 0.062 in | 1.57 mm | Female | Dual | 125 °C | -65 ░C | 10 | Card Extender | 20 | Polybutylene Terephthalate (PBT) | 2 | Gold | Phosphor Bronze | 4-40 Flush Mount Threaded Insert Top Opening | Loop Bellows | |||||
 Sullins Connector Solutions | Fits Female Edgecards | 0.76 Ám | 30 Áin | Solder | 2.54 mm | 0.1 in | Through Hole Right Angle | 0.062 in | 1.57 mm | Male | Dual | 125 °C | -65 ░C | 10 | 20 | Polybutylene Terephthalate (PBT) | 2 | Gold | Phosphor Bronze | Flush Mount Top Opening Unthreaded | 0.125 " | 3.18 mm | |||||
 Sullins Connector Solutions | Fits Female Edgecards | 0.76 Ám | 30 Áin | Solder | 2.54 mm | 0.1 in | Through Hole Right Angle | 0.062 in | 1.57 mm | Male | Dual | 125 °C | -65 ░C | 10 | 20 | Polybutylene Terephthalate (PBT) | 2 | Gold | Phosphor Bronze | ||||||||
Sullins Connector Solutions | Non Specified - Dual Edge | 0.76 Ám | 30 Áin | Solder | 2.54 mm | 0.1 in | Through Hole | 0.062 in | 1.57 mm | Female | Single | 125 °C | -65 ░C | 10 | Polybutylene Terephthalate (PBT) | 1 | Gold | Phosphor Bronze | Side Mount Opening Unthreaded | Cantilever | 0.125 in | 3.18 mm |
