307-039 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 39POS 0.156
| Part | Material - Insulation | Termination Rows | Color | Card Type | Read Out | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Operating Temperature [Min] | Operating Temperature [Max] | Card Thickness [Max] | Card Thickness [Min] | Mounting Type | Contact Finish | Contact Material | Gender | Number of Rows | Contact Type | Contact Finish Thickness | Contact Finish Thickness | Pitch | Pitch | Termination | Number of Positions/Bay/Row | Number of Positions | Number of Rows [custom] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 1 | Green | Non Specified - Single Edge | Single | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Gold | Copper Alloy | Female | 1 | Semi Bellows | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | Solder Eyelet(s) | 39 | 39 | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | Green | Non Specified - Single Edge | Single | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Gold | Copper Alloy | Female | 1 | Semi Bellows | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | Solder | 39 | 39 | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | Green | Non Specified - Single Edge | Single | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Tin | Copper Alloy | Female | 1 | Semi Bellows | 3.96 mm | 0.156 in | Solder | 39 | 39 | ||||
 EDAC Inc. | Polyester Thermoplastic | 1 | Green | Non Specified - Dual Edge | Dual | Flush Mount M3 Threaded Insert Top Opening | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Tin | Copper Alloy | Female | Semi Bellows | 3.96 mm | 0.156 in | Solder Eyelet(s) | 39 | 78 | 2 | ||||||
 EDAC Inc. | Polyester Thermoplastic | 1 | Green | Non Specified - Single Edge | Single | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Tin | Copper Alloy | Female | 1 | Semi Bellows | 3.96 mm | 0.156 in | Solder | 39 | 39 | |||||||
 EDAC Inc. | Polyester Thermoplastic | 1 | Green | Non Specified - Single Edge | Single | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Gold | Copper Alloy | Female | 1 | Semi Bellows | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | Solder | 39 | 39 | |||||
 EDAC Inc. | Polyester Thermoplastic | 1 | Green | Non Specified - Dual Edge | Dual | 4-40 Flush Mount Threaded Insert Top Opening | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Tin | Copper Alloy | Female | Semi Bellows | 3.96 mm | 0.156 in | Solder Eyelet(s) | 39 | 78 | 2 | Card Guides | |||||
 EDAC Inc. | Polyester Thermoplastic | 1 | Green | Non Specified - Dual Edge | Dual | 4-40 Flush Mount Threaded Insert Top Opening | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Gold | Copper Alloy | Female | Semi Bellows | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | Wire Wrap | 39 | 78 | 2 | Card Guides | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | Green | Non Specified - Dual Edge | Dual | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Tin | Copper Alloy | Female | Semi Bellows | 3.96 mm | 0.156 in | Solder Eyelet(s) | 39 | 78 | 2 | |||||||
 EDAC Inc. | Polyester Thermoplastic | 1 | Green | Non Specified - Single Edge | Single | 4-40 Flush Mount Threaded Insert Top Opening | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Tin | Copper Alloy | Female | 1 | Semi Bellows | 3.96 mm | 0.156 in | Solder | 39 | 39 | Card Guides |
