5192C Series
Manufacturer: ALPHA WIRE
Beta
⌘K
CABLE 2COND 22AWG BLK SHLD 1000'
| Part | Shield Coverage | Shield Material | Wire Gauge | Jacket (Insulation) Material | Jacket Color | Usage | Operating Temperature [Min] | Operating Temperature [Max] | Voltage | Conductor Material | Features | Cable Type | Number of Conductors | Shield Type | Jacket (Insulation) Thickness | Jacket (Insulation) Thickness | Length | Length | Conductor Strand [custom] | Conductor Strand [custom] | Ratings | Conductor Insulation |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 ALPHA WIRE | 100 % | Aluminum | 22 AWG | Poly-Vinyl Chloride (PVC) | Black | Communication Control | -35 °C | 105 ░C | 300 VDC | Copper Tinned | Biological Compatibility Drain Wire Rip Cord | Multi-Conductor | 2 | Foil | 0.813 mm | 0.032 in | 304.8 m | 1000 ft | 30 AWG | 7 | ISO 10993 | Poly-Vinyl Chloride (PVC) |
 ALPHA WIRE | 100 % | Aluminum | 22 AWG | Poly-Vinyl Chloride (PVC) | Slate | Communication Control | -35 °C | 105 ░C | 300 VDC | Copper Tinned | Biological Compatibility Drain Wire Rip Cord | Multi-Conductor | 2 | Foil | 0.813 mm | 0.032 in | 304.8 m | 1000 ft | 30 AWG | 7 | ISO 10993 | Poly-Vinyl Chloride (PVC) |
