629-M25 Series
Manufacturer: EDAC Inc.
Beta
⌘K
629M SERIES RIGHT ANGLE D-SUB PL
| Part | Contact Material | Dielectric Material | Operating Temperature [Min] | Operating Temperature [Max] | Color | Features | Shell Size, Connector Layout | Shell Size, Connector Layout [x] | Current Rating (Amps) | Shell Material, Finish | Flange Feature | Contact Finish Thickness | Contact Finish Thickness | Contact Type | Connector Type | Material Flammability Rating | Backset Spacing | Backset Spacing | Contact Finish | Mounting Type | Number of Rows [custom] | Number of Positions | Connector Style | Termination | Contact Finish Thickness | Flange Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Copper Alloy | Polyamide (PA6T) Nylon 6T | -55 C | 125 °C | Black | Grounding Indents Mounting Brackets Shielded | B DB | 3 | 5 A | Nickel Plated Steel | Board Side (4-40) | 0.38 µm | 15 µin | Signal | Plug Male Pins | UL94 V-0 | 9.4 mm | 0.37 in | Gold | Right Angle Through Hole | 2 | 25 | Combo D-Sub | Solder | ||
 EDAC Inc. | Copper Alloy | Polyamide (PA6T) Nylon 6T | -55 C | 125 °C | Black | Grounding Indents Shielded | B DB | 3 | 5 A | Nickel Plated Steel | Housing/Shell (Unthreaded) | 0.38 µm | 15 µin | Signal | Plug Male Pins | UL94 V-0 | 9.4 mm | 0.37 in | Gold | Right Angle Through Hole | 2 | 25 | Combo D-Sub | Solder | ||
 EDAC Inc. | Copper Alloy | Polyamide (PA6T) Nylon 6T | -55 C | 125 °C | Black | Grounding Indents Mounting Brackets Shielded | B DB | 3 | 5 A | Board Side (4-40) | Signal | Plug Male Pins | UL94 V-0 | 9.4 mm | 0.37 in | Gold | Right Angle Through Hole | 2 | 25 | Combo D-Sub | Solder | Flash | ||||
 EDAC Inc. | Copper Alloy | Polyamide (PA6T) Nylon 6T | -55 C | 125 °C | Black | Grounding Indents Shielded | B DB | 3 | 5 A | Nickel Plated Steel | Housing/Shell | 0.76 Ám | 30 Áin | Signal | Plug Male Pins | UL94 V-0 | 9.4 mm | 0.37 in | Gold | Right Angle Through Hole | 2 | 25 | Combo D-Sub | Solder | 4-40 | |
 EDAC Inc. | Copper Alloy | Polyamide (PA6T) Nylon 6T | -55 C | 125 °C | Black | Grounding Indents Shielded | B DB | 3 | 5 A | Housing/Shell | 0.76 Ám | 30 Áin | Signal | Plug Male Pins | UL94 V-0 | 9.4 mm | 0.37 in | Gold | Right Angle Through Hole | 2 | 25 | Combo D-Sub | Solder | 4-40 | ||
 EDAC Inc. | Copper Alloy | Polyamide (PA6T) Nylon 6T | -55 C | 125 °C | Black | Board Lock Grounding Indents Mounting Brackets Shielded | B DB | 3 | 5 A | 4-40 | Signal | Plug Male Pins | UL94 V-0 | 9.4 mm | 0.37 in | Gold | Right Angle Through Hole | 2 | 25 | Combo D-Sub | Solder | Flash | ||||
 EDAC Inc. | Copper Alloy | Polyamide (PA6T) Nylon 6T | -55 C | 125 °C | Black | Grounding Indents Mounting Brackets Shielded | B DB | 3 | 5 A | Nickel Plated Steel | 4-40 | 0.76 Ám | 30 Áin | Signal | Plug Male Pins | UL94 V-0 | 9.4 mm | 0.37 in | Gold | Right Angle Through Hole | 2 | 25 | Combo D-Sub | Solder | ||
 EDAC Inc. | Copper Alloy | Polyamide (PA6T) Nylon 6T | -55 C | 125 °C | Black | Grounding Indents Shielded | B DB | 3 | 5 A | Housing/Shell (Unthreaded) | 0.76 Ám | 30 Áin | Signal | Plug Male Pins | UL94 V-0 | 9.4 mm | 0.37 in | Gold | Right Angle Through Hole | 2 | 25 | Combo D-Sub | Solder | |||
 EDAC Inc. | Copper Alloy | Polyamide (PA6T) Nylon 6T | -55 C | 125 °C | Black | Grounding Indents Shielded | B DB | 3 | 5 A | Housing/Shell (Unthreaded) | 0.76 Ám | 30 Áin | Signal | Plug Male Pins | UL94 V-0 | 9.4 mm | 0.37 in | Gold | Right Angle Through Hole | 2 | 25 | Combo D-Sub | Solder | |||
 EDAC Inc. | Copper Alloy | Polyamide (PA6T) Nylon 6T | -55 C | 125 °C | Black | Grounding Indents Mounting Brackets Shielded | B DB | 3 | 5 A | Nickel Plated Steel | Housing/Shell | Signal | Plug Male Pins | UL94 V-0 | 9.4 mm | 0.37 in | Gold | Right Angle Through Hole | 2 | 25 | Combo D-Sub | Solder | Flash | 4-40 |
