C600 Series

Manufacturer: KEMET

Catalog

MULTILAYER CERAMIC CAPACITORS MLCC - LEADED 2000V 0.01UF X7R 10% LS=0.275 IN

Part	Lead Spacing	Lead Spacing	Size / Dimension	Size / Dimension	Package / Case	Temperature Coefficient	Lead Style	Tolerance	Voltage - Rated	Voltage - Rated	Applications	Capacitance	Mounting Type	Operating Temperature [Min]	Operating Temperature [Max]	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Features	Size / Dimension [y]	Size / Dimension [x]	Height - Seated (Max) [Max]	Height - Seated (Max)	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Size / Dimension [y]	Size / Dimension [x]
KEMET C627C103KGR5TA	0.275 in	6.98 mm	6.35 mm 9.4 mm	0.25 " 0.37 "	Radial	X7R	Straight	10 %	2000 V	2 kV	General Purpose	10000 pF	Through Hole	-55 C	125 °C	0.4 in	10.16 mm	High Voltage
KEMET C643C103MHR5TA
KEMET C627C102KDR5TA	0.275 in	6.98 mm	6.35 mm 9.4 mm	0.25 " 0.37 "	Radial	X7R	Straight	10 %	1000 V	1 kV	General Purpose	0.001 µF	Through Hole	-55 C	125 °C	0.4 in	10.16 mm	High Voltage
KEMET C630C332MDG5TA
KEMET C638C102KHG5TA	0.375 in	9.52 mm			Radial	C0G NP0	Formed Leads	10 %	3000 V	3 kV	General Purpose	0.001 µF	Through Hole	-55 C	125 °C			High Voltage	0.271 " 6.89 mm	0.469 in 11.9 mm	0.62 in	15.74 mm
KEMET C668C105KDR5TA	0.675 in	17.14 mm			Radial	X7R	Formed Leads	10 %	1000 V	1 kV	General Purpose	1 µF	Through Hole	-55 C	125 °C			High Voltage	6.89 mm	19.56 mm			23.87 mm	0.94 in	0.271 in	0.77 in
KEMET C631C124MCR5TA	0.3 in	7.62 mm			Radial	X7R	Formed Leads - Kinked	20 %	500 V		Bypass Decoupling	0.12 µF	Through Hole	-55 C	125 °C			High Voltage	5.08 mm	11.4 mm	0.44 "	11.17 mm			0.2 in	0.449 "
