857-082 Series
Manufacturer: EDAC Inc.
Catalog
CONN EDGE DUAL FMALE 82POS 0.156
...
| Part | Termination Rows [custom] | Material - Insulation | Pitch | Pitch | Gender | Read Out | Number of Rows [custom] | Contact Finish | Color | Contact Material | Contact Type | Card Thickness [Max] | Card Thickness [Min] | Termination | Card Type | Operating Temperature [Max] | Operating Temperature [Min] | Mounting Type | Number of Positions/Bay/Row | Number of Positions | Contact Finish Thickness | Contact Finish Thickness | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 3.96 mm | 0.156 in | Female | Dual | 2 | Gold | Black | Copper Alloy | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder Eyelet(s) | Non Specified - Dual Edge | 125 °C | -40 C | Through Hole | 41 | 82 | 0.25 Ám | 10 Áin | ||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 3.96 mm | 0.156 in | Female | Dual | 2 | Tin | Black | Copper Alloy | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Non Specified - Dual Edge | 125 °C | -40 C | Through Hole | 41 | 82 | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | |||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 3.96 mm | 0.156 in | Female | Dual | 2 | Gold | Black | Copper Alloy | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder Eyelet(s) | Non Specified - Dual Edge | 125 °C | -40 C | Through Hole | 41 | 82 | 0.25 Ám | 10 Áin | Flush Mount M3 Threaded Insert Top Opening | |||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 3.96 mm | 0.156 in | Female | Single | 2 | Tin | Black | Copper Alloy | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Non Specified - Dual Edge | 125 °C | -40 C | Right Angle Through Hole | 41 | 82 | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | |||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 3.96 mm | 0.156 in | Female | Dual | 2 | Tin | Black | Copper Alloy | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Non Specified - Dual Edge | 125 °C | -40 C | Through Hole | 41 | 82 | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | |||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 3.96 mm | 0.156 in | Female | Dual | 2 | Tin | Black | Copper Alloy | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Non Specified - Dual Edge | 125 °C | -40 C | Through Hole | 41 | 82 | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | |||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 3.96 mm | 0.156 in | Female | Dual | 2 | Gold | Black | Copper Alloy | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Non Specified - Dual Edge | 125 °C | -40 C | Board Edge Straddle Mount | 41 | 82 | 0.25 Ám | 10 Áin | Flush Mount M3 Threaded Insert Top Opening | Card Extender | ||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 3.96 mm | 0.156 in | Female | Dual | 2 | Tin | Black | Copper Alloy | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Non Specified - Dual Edge | 125 °C | -40 C | Through Hole | 41 | 82 | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | |||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 3.96 mm | 0.156 in | Female | Dual | 2 | Tin | Black | Copper Alloy | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Non Specified - Dual Edge | 125 °C | -40 C | Through Hole | 41 | 82 | 4-40 Flush Mount Threaded Insert Top Opening | |||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 3.96 mm | 0.156 in | Female | Single | 2 | Tin | Black | Copper Alloy | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Non Specified - Dual Edge | 125 °C | -40 C | Right Angle Through Hole | 41 | 82 | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm |
