BMS Series

Catalog

AUDIO TRANSFORMERS / SIGNAL TRANSFORMERS MDL SIN XFMR AEC-Q200

Part	Mounting Type	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Height - Seated (Max)	Turns Ratio - Primary:Secondary	Inductance	Operating Temperature [Max]	Operating Temperature [Min]	Qualification	Transformer Type	Grade	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]
Pulse Electronics HM2106NL	Surface Mount	5.75 mm	0.226 in
Pulse Electronics HM2166NL	Surface Mount		0.236 "	6 mm	1:1	150 µH	125 °C	-40 C	AEC-Q200	Battery Management	Automotive	16.34 mm	9.5 mm	0.643 in	0.374 in
Pulse Electronics HM2103NL	Surface Mount	5.72 mm	0.225 in			150 µH						7.62 mm	9.4 mm	0.3 "	0.37 in
Pulse Electronics HM2113ZNL	Surface Mount	3.45 mm	0.136 in		1:1	150 µH 450 µH	125 °C	-40 C				9 mm	12.15 mm	0.354 in	0.478 in
Pulse Electronics HM1237NL	Surface Mount	5.72 mm	0.225 in		1:1	650 µH						11.56 mm	9.53 mm	0.455 in	0.375 in
