6402FE Series
Manufacturer: Belden Inc.
Beta
⌘K
CABLE 4COND 20AWG NATURAL
| Part | Shield Coverage | Shield Material | Jacket Color | Number of Conductors | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Operating Temperature [Max] | Operating Temperature [Min] | Jacket (Insulation) Material | Jacket (Insulation) Thickness [x] | Jacket (Insulation) Thickness [x] | Conductor Strand [custom] | Conductor Strand [custom] | Wire Gauge | Length | Length | Cable Type | Features | Conductor Insulation | Conductor Material | Usage | Shield Type | Ratings | Voltage |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Belden Inc. | 100 % | Aluminum | Natural | 4 | 4.17 mm | 0.164 in | 75 ░C | 0 °C | Low Smoke Poly-Vinyl Chloride (LSPVC) Plenum | 0.381 mm | 0.015 in | 28 AWG | 7 | 20 AWG | 304.8 m | 1000 ft | Multi-Conductor | Drain Wire Rip Cord | Low Smoke Poly-Vinyl Chloride (LSPVC) | Copper Bare | Security Sound | Foil | UL Style CMP | 300 VDC |
Belden Inc. | 100 % | Aluminum | Natural | 4 | 4.17 mm | 0.164 in | 75 ░C | 0 °C | Low Smoke Poly-Vinyl Chloride (LSPVC) Plenum | 0.381 mm | 0.015 in | 28 AWG | 7 | 20 AWG | 304.8 m | 1000 ft | Multi-Conductor | Drain Wire Rip Cord | Low Smoke Poly-Vinyl Chloride (LSPVC) | Copper Bare | Security Sound | Foil | UL Style CMP | 300 VDC |
