SMC392 Series

Catalog

DISP 14SEG 0.39 DUAL YELLOW 10DI

Part	Common Pin	Wavelength - Peak	Millicandela Rating	Current - Test	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [y]	Number of Characters	Display Type	Voltage - Forward (Vf) (Typ)	Color	Power Dissipation (Max) [Max]	Digit/Alpha Size	Digit/Alpha Size	Package / Case	Power Dissipation (Max)
American Opto Plus LED SMC392LY G/W	Common Cathode	593 nm	30 mcd	20 mA	3.8 mm	0.15 "	0.591 in	0.772 in	15 mm	19.6 mm	2	7-Segment	2 V	Yellow	70 mW	10 mm	0.39 in	10-DIP
American Opto Plus LED SMC392LB G/W	Common Cathode		40 mcd	20 mA	3.8 mm	0.15 "	0.591 in	0.772 in	15 mm	19.6 mm	2	7-Segment	3.2 V	Blue		10 mm	0.39 in	10-DIP	120 mW
