396-029 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 29POS 0.125
| Part | Material - Insulation | Termination Rows | Contact Finish | Read Out | Contact Material | Number of Positions/Bay/Row | Number of Rows | Pitch | Pitch | Termination | Number of Positions | Color | Contact Type | Gender | Card Type | Mounting Type | Operating Temperature [Min] | Operating Temperature [Max] | Card Thickness [Max] | Card Thickness [Min] | Flange Feature | Contact Finish Thickness | Contact Finish Thickness | Flange Feature [diameter] | Flange Feature [diameter] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 1 | Gold | Single | Copper Alloy | 29 | 1 | 3.18 mm | 0.125 in | Solder Wire Wrap | 29 | Black | Cantilever | Female | Non Specified - Single Edge | Right Angle Through Hole | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 4-40 Threaded Insert Top Mount Opening | 0.25 Ám | 10 Áin | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | Gold | Single | Copper Alloy | 29 | 1 | 3.18 mm | 0.125 in | Wire Wrap | 29 | Black | Cantilever | Female | Non Specified - Single Edge | Through Hole | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 4-40 Threaded Insert Top Mount Opening | 0.25 Ám | 10 Áin | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | Gold | Single | Copper Alloy | 29 | 1 | 3.18 mm | 0.125 in | Solder | 29 | Black | Cantilever | Female | Non Specified - Single Edge | Through Hole | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Floating Bobbin Flush Mount | 0.25 Ám | 10 Áin | 0.116 " | 2.95 mm | |
 EDAC Inc. | Polyester Thermoplastic | 1 | Gold | Single | Copper Alloy | 29 | 1 | 3.18 mm | 0.125 in | Wire Wrap | 29 | Black | Cantilever | Female | Non Specified - Single Edge | Through Hole | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | M3 Threaded Insert Top Mount Opening | 0.25 Ám | 10 Áin | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | Gold | Single | Copper Alloy | 29 | 1 | 3.18 mm | 0.125 in | Solder | 29 | Black | Cantilever | Female | Non Specified - Single Edge | Through Hole | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 4-40 Flush Mount Threaded Insert Top Opening | 0.25 Ám | 10 Áin | Card Guides | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | Gold | Single | Copper Alloy | 29 | 1 | 3.18 mm | 0.125 in | Wire Wrap | 29 | Black | Cantilever | Female | Non Specified - Single Edge | Through Hole | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 4-40 Threaded Insert Top Mount Opening | 0.25 Ám | 10 Áin | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | Gold | Single | Copper Alloy | 29 | 1 | 3.18 mm | 0.125 in | Solder | 29 | Black | Cantilever | Female | Non Specified - Single Edge | Through Hole | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 4-40 Threaded Insert Top Mount Opening | 0.25 Ám | 10 Áin | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | Gold | Single | Copper Alloy | 29 | 1 | 3.18 mm | 0.125 in | Solder Wire Wrap | 29 | Black | Cantilever | Female | Non Specified - Single Edge | Right Angle Through Hole | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 4-40 Threaded Insert Top Mount Opening | 0.25 Ám | 10 Áin | Card Guides | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | Gold | Single | Copper Alloy | 29 | 1 | 3.18 mm | 0.125 in | Wire Wrap | 29 | Black | Cantilever | Female | Non Specified - Single Edge | Through Hole | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Flush Mount M3 Threaded Insert Top Opening | 0.25 Ám | 10 Áin | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | Gold | Single | Copper Alloy | 29 | 1 | 3.18 mm | 0.125 in | Solder | 29 | Black | Cantilever | Female | Non Specified - Single Edge | Through Hole | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Flush Mount Top Opening Unthreaded | 0.25 Ám | 10 Áin | 0.128 " | 3.25 mm |
