1241.6697 Series
Manufacturer: SCHURTER Inc.
Beta
⌘K
SWITCH PUSHBUTTON SPDT 5A 125V
| Part | Electrical Life | Mechanical Life | Illumination Type, Color | Actuator Marking | Illumination Voltage (Nominal) | Switch Function | Ingress Protection | Operating Temperature [Max] | Operating Temperature [Min] | Type | Voltage Rating - AC | Termination Style | Current Rating (Amps) | Mounting Type | Circuit | Panel Cutout Dimensions [diameter] | Color - Actuator/Cap | Actuator Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 SCHURTER Inc. | 200000 Cycles | 1500000 Cycles | LED Red | No Marking | 1.9 VDC | On-Mom | IP40 | 85 °C | -25 °C | Anti-Vandal Illuminated | 125 V | Quick Connect - 0.110" (2.8mm) | 5 A | Panel Mount Front | SPDT | 22.3 mm | Silver | Button Flush Round |
 SCHURTER Inc. | 200000 Cycles | 1500000 Cycles | Green LED | No Marking | 2.1 VDC | On-Mom | IP40 | 85 °C | -25 °C | Anti-Vandal Illuminated | 125 V | Quick Connect - 0.110" (2.8mm) | 5 A | Panel Mount Front | SPDT | 22.3 mm | Silver | Button Flush Round |
