Potentiometers 27mm Rotary Panel Potentiometer
Potentiometers 27mm Rotary Panel Potentiometer
| Part | Adjustment Type | Number of Gangs | Resistive Material | Taper | Actuator Length [x] | Actuator Length [x] | Termination Style | Rotation | Bushing Thread | Actuator Diameter [diameter] | Actuator Diameter [diameter] | Actuator Type | Number of Turns | Built in Switch | Mounting Type | Resistance (Ohms) | Tolerance | Power (Watts) | Size - Body [diameter] | Size - Body [diameter] | Size - Body | Size - Body [z] | Size - Body [z] | Resistance (Ohms) | Features | Resistance (Ohms) [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
TT Electronics/BI | User Defined | 1 | Conductive Plastic | Linear | 0.875 in | 22.23 mm | Solder Lug | 312 ° | 3/8-32 | 6.35 mm | 0.25 in | Slotted | 1 | None | Panel Mount | 1k | 10 % | 2 W | 26.67 mm | 1.05 " | Round | |||||
 TT Electronics/BI | User Defined | 1 | Conductive Plastic | Linear | 0.875 in | 22.23 mm | Solder Lug | 312 ° | 3/8-32 | 6.35 mm | 0.25 in | Slotted | 1 | None | Panel Mount | 10 % | 2 W | 26.67 mm | 1.05 " | 0.562 " | 14.27 mm | 5 kOhms | ||||
TT Electronics/BI | User Defined | 1 | Conductive Plastic | Linear | 0.875 in | 22.23 mm | Solder Lug | 312 ° | 3/8-32 | 6.35 mm | 0.25 in | Round | 1 | None | Panel Mount | 10k | 10 % | 2 W | 26.67 mm | 1.05 " | Round | Sealed | ||||
TT Electronics/BI | User Defined | 1 | Conductive Plastic | Linear | 0.875 in | 22.23 mm | Solder Lug | 312 ° | 3/8-32 | 6.35 mm | 0.25 in | Slotted | 1 | None | Panel Mount | 10 % | 2 W | 26.67 mm | 1.05 " | Round | 5 kOhms | Sealed | ||||
TT Electronics/BI | User Defined | 1 | Conductive Plastic | Linear | 50.8 mm | 50.8 mm | Solder Lug | 312 ° | 3/8-32 | 6.35 mm | 0.25 in | Slotted | 1 | None | Panel Mount | 10 % | 2 W | 26.67 mm | 1.05 " | Round | 20 kOhms | |||||
TT Electronics/BI | User Defined | 1 | Conductive Plastic | Linear | 0.875 in | 22.23 mm | Solder Lug | 312 ° | 3/8-32 | 6.35 mm | 0.25 in | Round | 1 | None | Panel Mount | 10 % | 2 W | 26.67 mm | 1.05 " | Round | 20 kOhms | |||||
TT Electronics/BI | User Defined | 1 | Conductive Plastic | Linear | 0.875 in | 22.23 mm | Solder Lug | 312 ° | 3/8-32 | 6.35 mm | 0.25 in | Flatted | 1 | None | Panel Mount | 10 % | 2 W | 26.67 mm | 1.05 " | Round | 5 kOhms | Sealed | ||||
TT Electronics/BI | User Defined | 1 | Conductive Plastic | Linear | 0.875 in | 22.23 mm | Solder Lug | 312 ° | 3/8-32 | 6.35 mm | 0.25 in | Slotted | 1 | None | Panel Mount | 10k | 10 % | 2 W | 26.67 mm | 1.05 " | Round | |||||
TT Electronics/BI | User Defined | 1 | Conductive Plastic | Linear | 0.875 in | 22.23 mm | Solder Lug | 312 ° | 3/8-32 | 6.35 mm | 0.25 in | Slotted | 1 | None | Panel Mount | 10k | 10 % | 2 W | 26.67 mm | 1.05 " | Round | Sealed | ||||
TT Electronics/BI | User Defined | 1 | Conductive Plastic | Linear | 0.875 in | 22.23 mm | Solder Lug | 312 ° | 3/8-32 | 6.35 mm | 0.25 in | Slotted | 1 | None | Panel Mount | 10 % | 2 W | 26.67 mm | 1.05 " | Round | Sealed | 2.5 kOhms |
