357-017 Series
Manufacturer: EDAC Inc.
Catalog
CARD EDGE CONNECTOR ROHS COMPLIANT: YES
...
| Part | Contact Type | Contact Material | Number of Rows | Termination Rows | Contact Finish | Operating Temperature [Min] | Operating Temperature [Max] | Contact Finish Thickness | Contact Finish Thickness | Card Type | Number of Positions | Card Thickness [Min] | Card Thickness [Min] | Card Thickness [Max] | Card Thickness [Max] | Mounting Type | Flange Feature | Material - Insulation | Gender | Color | Termination | Read Out | Pitch [x] | Pitch [x] | Features | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Semi Bellows | Copper Alloy | 2 | 1 | Gold | -40 °C | 105 ░C | 10 Áin | 0.25 Ám | Non Specified - Dual Edge | 34 | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Through Hole Right Angle | Flush Mount M3 Threaded Insert Top Opening | Polyester Thermoplastic | Female | Black | Wire Wrap | Dual | 0.156 in | 3.96 mm | |||
 EDAC Inc. | Semi Bellows | Copper Alloy | 2 | 1 | Tin | -40 °C | 105 ░C | Non Specified - Dual Edge | 34 | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Through Hole Right Angle | 4-40 Flush Mount Threaded Insert Top Opening | Polyester Thermoplastic | Female | Black | Solder | Dual | 0.156 in | 3.96 mm | Card Guides | ||||
EDAC Inc. | Semi Bellows | Copper Alloy | 1 | 1 | Tin | -40 °C | 105 ░C | Non Specified - Single Edge | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Through Hole Right Angle | Floating Bobbin Flush Mount | Polyester Thermoplastic | Female | Black | Solder | Single | 0.156 in | 3.96 mm | 0.116 in | 2.95 mm | ||||
 EDAC Inc. | Semi Bellows | Copper Alloy | 1 | 1 | Gold | -40 °C | 105 ░C | 10 Áin | 0.25 Ám | Non Specified - Single Edge | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Through Hole | 4-40 Flush Mount Threaded Insert Top Opening | Polyester Thermoplastic | Female | Black | Wire Wrap | Single | 0.156 in | 3.96 mm | ||||
 EDAC Inc. | Semi Bellows | Copper Alloy | 1 | 1 | Gold | -40 °C | 105 ░C | 10 Áin | 0.25 Ám | Non Specified - Single Edge | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Through Hole | 4-40 Flush Mount Threaded Insert Top Opening | Polyester Thermoplastic | Female | Black | Solder | Single | 0.156 in | 3.96 mm | ||||
 EDAC Inc. | Semi Bellows | Copper Alloy | 1 | 1 | Gold | -40 °C | 105 ░C | 10 Áin | 0.25 Ám | Non Specified - Single Edge | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Through Hole | 4-40 Flush Mount Threaded Insert Top Opening | Polyester Thermoplastic | Female | Black | Solder | Single | 0.156 in | 3.96 mm | Card Guides | |||
 EDAC Inc. | Semi Bellows | Copper Alloy | 1 | 1 | Gold | -40 °C | 105 ░C | 10 Áin | 0.25 Ám | Non Specified - Single Edge | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Through Hole | Flush Mount Side Opening Unthreaded | Polyester Thermoplastic | Female | Black | Solder | Single | 0.156 in | 3.96 mm | 0.128 " | 3.25 mm | ||
 EDAC Inc. | Semi Bellows | Copper Alloy | 2 | 1 | Tin | -40 °C | 105 ░C | Non Specified - Dual Edge | 34 | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Through Hole Right Angle | 4-40 Flush Mount Threaded Insert Top Opening | Polyester Thermoplastic | Female | Black | Solder | Dual | 0.156 in | 3.96 mm | |||||
 EDAC Inc. | Semi Bellows | Copper Alloy | 1 | 1 | Gold | -40 °C | 105 ░C | 10 Áin | 0.25 Ám | Non Specified - Single Edge | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Through Hole | Floating Bobbin Flush Mount | Polyester Thermoplastic | Female | Black | Wire Wrap | Single | 0.156 in | 3.96 mm | 0.116 in | 2.95 mm | ||
 EDAC Inc. | Semi Bellows | Copper Alloy | 1 | 1 | Tin | -40 °C | 105 ░C | Non Specified - Single Edge | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Through Hole Right Angle | Flush Mount Top Opening Unthreaded | Polyester Thermoplastic | Female | Black | Solder | Single | 0.156 in | 3.96 mm | 0.128 " | 3.25 mm |
