306-022 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 44POS 0.156
| Part | Termination Rows | Material - Insulation | Mounting Type | Features | Read Out | Pitch | Pitch | Flange Feature | Contact Finish | Operating Temperature [Min] | Operating Temperature [Max] | Termination | Contact Type | Gender | Number of Positions | Number of Rows [custom] | Card Thickness [Max] | Card Thickness [Min] | Contact Material | Card Type | Color | Number of Positions/Bay/Row | Contact Finish Thickness | Contact Finish Thickness | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyester Thermoplastic | Panel Mount Through Hole | Card Guides | Dual | 3.96 mm | 0.156 in | 4-40 Flush Mount Threaded Insert Top Opening | Tin | -40 C | 105 ░C | Solder | Cantilever | Female | 44 | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Non Specified - Dual Edge | Green | 22 | ||||
 EDAC Inc. | 1 | Polyester Thermoplastic | Panel Mount Through Hole | Card Guides | Dual | 3.96 mm | 0.156 in | 4-40 Flush Mount Threaded Insert Top Opening | Gold | -40 C | 105 ░C | Solder | Cantilever | Female | 44 | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Non Specified - Dual Edge | Green | 22 | 0.25 Ám | 10 Áin | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | Panel Mount Through Hole | Dual | 3.96 mm | 0.156 in | Flush Mount Top Opening Unthreaded | Tin | -40 C | 105 ░C | Solder | Cantilever | Female | 44 | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Non Specified - Dual Edge | Green | 22 | 0.156 " | 3.96 mm | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | Through Hole | Dual | 3.96 mm | 0.156 in | Flush Mount Top Opening Unthreaded | Gold | -40 C | 105 ░C | Solder | Cantilever | Female | 44 | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Non Specified - Dual Edge | Green | 22 | 0.128 " | 3.25 mm | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | Through Hole | Dual | 3.96 mm | 0.156 in | Tin | -40 C | 105 ░C | Solder | Cantilever | Female | 44 | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Non Specified - Dual Edge | Green | 22 | ||||||
 EDAC Inc. | 1 | Polyester Thermoplastic | Through Hole | Dual | 3.96 mm | 0.156 in | Flush Mount Top Opening Unthreaded | Gold | -40 C | 105 ░C | Solder | Cantilever | Female | 44 | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Non Specified - Dual Edge | Green | 22 | 0.25 Ám | 10 Áin | 0.156 " | 3.96 mm | |
 EDAC Inc. | 1 | Polyester Thermoplastic | Panel Mount | Dual | 3.96 mm | 0.156 in | 4-40 Flush Mount Threaded Insert Top Opening | Gold | -40 C | 105 ░C | Solder Eyelet(s) | Cantilever | Female | 44 | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Non Specified - Dual Edge | Green | 22 | 0.25 Ám | 10 Áin | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | Panel Mount Through Hole | Card Guides | Dual | 3.96 mm | 0.156 in | 4-40 Flush Mount Threaded Insert Top Opening | Tin | -40 C | 105 ░C | Solder | Cantilever | Female | 44 | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Non Specified - Dual Edge | Green | 22 | ||||
EDAC Inc. | 1 | Polyester Thermoplastic | Dual | 3.96 mm | 0.156 in | Flush Mount Top Opening Unthreaded | Gold | -40 C | 105 ░C | Cantilever | Female | 44 | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Non Specified - Dual Edge | Green | 22 | 0.128 " | 3.25 mm | |||||
 EDAC Inc. | 1 | Polyester Thermoplastic | Panel Mount Through Hole | Card Guides | Dual | 3.96 mm | 0.156 in | 4-40 Flush Mount Threaded Insert Top Opening | Gold | -40 C | 105 ░C | Solder | Cantilever | Female | 44 | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Non Specified - Dual Edge | Green | 22 | 0.25 Ám | 10 Áin |
