627-7W2 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN D-SUB PLUG 7P PNL MNT SLDR
| Part | Contact Material | Color | Operating Temperature [Min] | Operating Temperature [Max] | Dielectric Material | Voltage Rating | Contact Finish Thickness | Connector Style | Number of Positions | Number of Positions [custom] | Number of Positions [custom] | Shell Material, Finish | Contact Finish | Termination | Current Rating (Amps) | Material Flammability Rating | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout [custom] | Contact Type | Number of Rows [custom] | Connector Type | Flange Feature | Mounting Type | Features | Contact Finish Thickness | Contact Finish Thickness | Current Rating (Amps) | Number of Positions [custom] | Number of Positions [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Copper Alloy | Black | -55 C | 125 °C | Polyester Thermoplastic | 125 VDC | Flash | Combo D-Sub | 7 | 5 | 2 | Nickel Plated Steel | Gold | Solder | 20A 5A | UL94 V-0 | A DA | 2 | 7W2 | Signal and Power | 2 | Plug Male Pins | 4-40 | Panel Mount Through Hole | Board Lock Grounding Indents Shielded | |||||
 EDAC Inc. | Copper Alloy | Black | -55 C | 125 °C | Polyester Thermoplastic | 125 VDC | Combo D-Sub | 7 | 5 | 2 | Nickel Plated Steel | Gold | 10A 5A | UL94 V-0 | A DA | 2 | 7W2 | Signal and Power | 2 | Plug Male Pins | Board Side (4-40) | Free Hanging (In-Line) | Grounding Indents Shielded | 30 Áin | 0.76 Ám | |||||
 EDAC Inc. | Copper Alloy | Black | -55 C | 125 °C | Polyester Thermoplastic | 125 VDC | Flash | Combo D-Sub | 7 | 5 | 2 | Gold | Solder | UL94 V-0 | A DA | 2 | 7W2 | Signal and Power | 2 | Plug Male Pins | Board Side (4-40) | Through Hole | Board Lock Grounding Indents Shielded | 5 A 30 A | ||||||
 EDAC Inc. | Copper Alloy | Black | -55 C | 125 °C | Polyester Thermoplastic | 125 VDC | Combo D-Sub | 7 | 5 | 2 | Nickel Plated Steel | Gold | Solder | 10A 5A | UL94 V-0 | A DA | 2 | 7W2 | Signal and Power | 2 | Plug Male Pins | M3 | Panel Mount Through Hole | Board Lock Grounding Indents Shielded | 30 Áin | 0.76 Ám | ||||
 EDAC Inc. | Copper Alloy | Black | -55 C | 125 °C | Polyester Thermoplastic | 125 VDC | Combo D-Sub | Nickel Plated Steel | Gold | Solder | UL94 V-0 | A DA | 2 | 7W2 | Coax Signal | 2 | Plug Male Pins | M3 | Panel Mount Through Hole | Grounding Indents Shielded | 30 Áin | 0.76 Ám | 5 | 2 | ||||||
 EDAC Inc. | Copper Alloy | Black | -55 C | 125 °C | Polyester Thermoplastic | 125 VDC | Combo D-Sub | Gold | Solder | UL94 V-0 | A DA | 2 | 7W2 | Coax Signal | 2 | Plug Male Pins | Board Side (4-40) | Through Hole | Board Lock Grounding Indents Shielded | 30 Áin | 0.76 Ám | 5 | 2 | |||||||
 EDAC Inc. | Copper Alloy | Black | -55 C | 125 °C | Polyester Thermoplastic | 125 VDC | Flash | Combo D-Sub | 7 | 5 | 2 | Gold | Solder | 10A 5A | UL94 V-0 | A DA | 2 | 7W2 | Signal and Power | 2 | Plug Male Pins | Board Side (M3) | Through Hole | Board Lock Grounding Indents Shielded | ||||||
 EDAC Inc. | Copper Alloy | Black | -55 C | 125 °C | Polyester Thermoplastic | 125 VDC | Flash | Combo D-Sub | 7 | 5 | 2 | Nickel Plated Steel | Gold | Solder | 10A 5A | UL94 V-0 | A DA | 2 | 7W2 | Signal and Power | 2 | Plug Male Pins | Board Side (4-40) | Through Hole | Board Lock Grounding Indents Shielded | |||||
 EDAC Inc. | Copper Alloy | Black | -55 C | 125 °C | Polyester Thermoplastic | 125 VDC | Flash | Combo D-Sub | 7 | 5 | 2 | Nickel Plated Steel | Gold | Solder | UL94 V-0 | A DA | 2 | 7W2 | Signal and Power | 2 | Plug Male Pins | Housing/Shell (Unthreaded) | Through Hole | Grounding Indents Shielded | 5 A 30 A | |||||
 EDAC Inc. | Copper Alloy | Black | -55 C | 125 °C | Polyester Thermoplastic | 125 VDC | Flash | Combo D-Sub | 7 | 5 | 2 | Nickel Plated Steel | Gold | Solder | 10A 5A | UL94 V-0 | A DA | 2 | 7W2 | Signal and Power | 2 | Plug Male Pins | Board Side (4-40) | Panel Mount Through Hole | Grounding Indents Shielded |
